Height-adjustable surgeon's chair JG-B2

mobilepneumaticstainless steel

Short description

• Dental saddle stool model JG-B3 with adjustable backrest, gas-lift height adjustment (46–58 cm), 360° swivel and nylon twin-wheel casters — designed for dental clinics and training environments; multiple color options available.

Key features

• Ergonomic, extra-large padded seat and supportive backrest with high-density sponge for extended procedures and reduced operator fatigue.
• Smooth height adjustment via gas lift (46–58 cm) with hand lever; air spring travel up to 120 mm.
• Safety and durability: reinforced aluminum base, stainless-steel foot, iron plate under cushion for double protection; nylon twin-wheel casters for stable mobility.
• Multi-function: 360° seat swivel, adjustable back tilt (0–10°), easy rolling casters for efficient workflow.
• Standards & warranty: components meet ANSI/BIFMA X5.1 and EN 1335; SGS tested. Load capacity 450 kg. 1-year warranty (replacement under warranty conditions).

Dimensions & measurements
Backrest: 405 x 320 x 50 mm
Seat: 450 x 410 x 75 mm
Overall dimension (stool): 580 x 580 x 820 mm
Foot diameter: 560 mm
Max seat height (to ground): 580 mm
Min seat height (to ground): 460 mm
Air spring travel: within 120 mm
Angle of the backrest: 0–10°
Gross weight (G.W.): 11 KG
Packing size: 54.5 x 27.5 x 52 cm
Color: different colors available

Materials

• Seat material: micro fiber leather
• Base: heavy-duty aluminum
• Foot material: stainless steel
• Casters: nylon twin-wheel casters

Intended use

• Designed for dental clinics, dental training centers and similar professional medical environments requiring ergonomic seating, mobility and durable construction; compatible with dental simulators (e.g. Jingle Med) for integrated training.

Technical specifications

• Model: JG-B3
• Seat dimensions: 450 x 410 x 75 mm
• Backrest dimensions: 405 x 320 x 50 mm
• Stool dimension: 580 x 580 x 820 mm
• Seat height range: 460–580 mm
• Air spring travel: within 120 mm
• Backrest angle: 0–10°
• Foot diameter: 560 mm
• Seat material: micro fiber leather
• Base/foot material: heavy-duty aluminum and stainless steel
• Casters: nylon twin-wheel casters
• Load capacity: 450 KG
• Gross weight: 11 KG
• Packing size: 54.5 x 27.5 x 52 cm
• Functions: 360° swivel, height adjustable, adjustable back tilt, rolling casters
• Warranty: 1 year (replacement under warranty conditions)
