Lighting light JG-S2

for dental laboratoriesLEDon casters

Product overview
A dental chair LED light integrated with an HD monitor and camera recording kit for clinical documentation, patient education and real-time procedure monitoring. The system combines adjustable, daylight-balanced LED illumination with a high-definition camera and video management for clinical workflows.

Key features

• Light intensity: 3000–50000 lux
• Flare size: 16.0 × 9.0 cm (reference)
• Light source: 8 LEDs
• Color temperature: 4000 / 4500 / 5000 K (three-step)
• Magnification: 30× optical; 12× digital
• White balance range: 3000–7500 K
• Control: wireless remote control and touch keyboard
• Image sensor: Sony 1/28-inch CMOS
• Output: 1920 × 1080 @ 60 fps
• Autofocus: yes

Benefits
The integrated light and imaging kit provides bright, focused, daylight-balanced illumination for dental procedures while enabling high-quality image and video capture for documentation, case presentation and patient communication. Real-time display and recording support improved procedural control and teaching. LED illumination offers energy efficiency and long service life.

Technical specifications

• Intensity range: 3000–50000 lux
• Flare / beam size: 16.0 × 9.0 cm (measured)
• LED count: 8
• Color temperature steps: 4000 K / 4500 K / 5000 K
• Magnification: 30× optical; up to 12× digital
• White balance: 3000–7500 K
• Control modes: wireless remote + touch keyboard
• Sensor: Sony 1/28-inch CMOS
• Resolution / framerate: 1920 × 1080 @ 60 fps
• Autofocus: yes

Package contents

• Camera light ×1
• Mobile support ×1
• Video management software ×1
• HD display ×1
• PC computer ×1
• Keyboard ×1
• Mouse ×1
