Membrane permeation tester TR-0045

for the pharmaceutical industryfor medical researchbenchtop

The Side-Bi-Side Cell accurately measures the cumulative permeation amount and absorption rate of drugs across membranes, predicting the kinetic process of drug molecules entering the body via the skin or other media. Introduction The Side-Bi-Side Cell is dedicated to horizontal transdermal tests, primarily used for penetration experiments of liquid substances (e.g., solvents, reagents) through oral mucosa, gastric mucosa, intestinal mucosa, biological membranes, and other tissues. Features Precise and Stable Temperature Control:Temperature control accuracy reaches 0.20℃, with an adjustable range from room temperature to 70℃. Stirring and Timing Function:Rotation speed ranges from 0–999 rpm; freely programmable end time available. Multiple Diffusion Cell Specifications:Side-Bi-Side Cell with 4 mL and 15 mL horizontal diffusion cell (custom sizes supported). Exquisite Craftsmanship and Durability:The main body and internal components are made of stainless steel, ensuring a sturdy structure. Independent control of stirring and heating systems facilitates easy operation. Specifications Parameter - Specification Number of channels - 6 Speed control accuracy - 1 rpm Speed consistency of each channel - ≤0.5% Rotation mode - Forward rotation, reverse rotation Temperature control accuracy - 0.2℃
