Vascular lesion treatment laser LASEVIA

vulvo-vaginal rejuvenationlipolysisphysical biostimulation

Overview
LASEVIA is a multi-wavelength semiconductor (diode) laser platform combining selectable diode sources (configuration-dependent) to treat aesthetic, vascular and therapeutic indications across eight clinical specialties. Portable 15 kg console with an 11.6-inch Android smart touchscreen, Class 4 safety hardware, emergency laser stop and mechanical safety shutter.

Key platform highlights

• Multi-wavelength architecture: 450 / 635 / 980 / 1470 / 1940 nm (configuration dependent)
• Maximum output: up to 30 W+
• Emission modes: CW, single pulse, repeat pulse
• Pulse width: 25 µs – 10 s
• Repetition rate: 0.05 Hz – 50 kHz
• Fiber interface: SMA905 universal port (contact fibers 200 / 400 / 600 / 1000 µm; non-contact tips supported)
• 11.6" Android smart touchscreen with touch presets and one-tap protocol recall
• Portable desktop footprint with a single-handle carry frame (approx. 15 kg)

Clinical specialties (eight)

• Endolifting (deep 1940 nm fractional fiber for non-surgical lifting)
• Lipolysis (1470 / 980 nm ring-light fiber emulsification for mini-invasive body contouring)
• Spider vein & vascular (transdermal and endovenous coagulation at 980 / 1470 nm, plus 635 nm surface mode)
• Therapy · HILT Class IV (deep-tissue photobiomodulation for pain, inflammation and repair)
• LVR (non-ablative 635 nm vaginal rejuvenation / intimate health)
• Proctology (fiber-delivered coagulation for haemorrhoids and fistulas)
• EVLT (endovenous laser ablation using 1470 / 1940 nm sealed intraluminal approach)
• ENT (450 nm blue for minimally invasive soft-tissue surgery)

Wavelength architecture & factory configurations
Configuration A: 1940 nm · 1470 nm · 980 nm · 635 nm
Configuration B: 1470 nm · 980 nm · 450 nm · 635 nm

Configuration A — per-wavelength nominal outputs (example)
1940 nm — 10 W · 1470 nm — 15 W · 980 nm — 20 W · 635 nm — 500 mW · typical fiber: 200 µm

Configuration B — per-wavelength nominal outputs (example)
1470 nm — 15 W · 980 nm — 30 W · 450 nm — 8 W · 635 nm — 2 W · typical fibers: 200 / 400 µm

Emission & delivery

• Emission modes: CW · single pulse · repeat pulse
• Pulse width range: 25 µs – 10 s
• Repetition rates: 0.05 Hz – 50 kHz
• Delivery system: SMA905 fiber interface; supports contact fibers (200 / 400 / 600 / 1000 µm) and non-contact tips

Device ergonomics & safety

• 11.6" Android smart touchscreen, glove-friendly UI with presets and real-time energy readouts
• Emergency mushroom-style laser stop and mechanical safety shutter
• Class 4 laser product (professional use)

Handpieces, fibers & accessories (delivery ecosystem)

• Handpiece sets: Basic Handpiece Set (endolifting · lipolysis), Advanced Liposuction Set (lipolysis), SUPERSCAN Focus Set (spider vein · fractional), LVR Handpiece Set (intimate health), PM5 Therapy Set (therapy heads), disposable LVR and disposable surgical sets
• Fibers: High-power fiber (SMA905), Bare fiber (direct contact), Polyimide-coated fiber, Radial fiber (360° radial emission), Hemorrhoid fiber (cylindrical / conical emission, typically 600 µm)
• Accessories: Laser safety goggles, foot switch, fiber cutter, fiber stripper, optic connector cleaner

Clinical notes & typical uses

• Endolifting: deep 1940 nm fractional fiber remodels superficial and deep layers for non-surgical lifting of face, neck and body
• Lipolysis: ring-light fiber emulsifies adipose through micro-cannulas for precise mini-invasive contouring
• Spider vein & vascular: targeted 980 / 1470 nm coagulation for telangiectasia and varicose veins; 635 nm mode for surface vascular lesions
• EVLT: endovenous ablation using 1470 / 1940 nm water-absorbed wavelengths for in-office vein sealing
• Therapy (HILT Class IV): deep-tissue photobiomodulation for pain, inflammation and tissue repair
• ENT: 450 nm blue for minimally invasive soft-tissue surgery with minimal thermal damage

Certifications & compliance
CE · MDSAP · ISO 13485 · FDA-cleared therapeutic-laser instrument technology (platform built on these certified technologies).

Caractéristiques / spécifications techniques

• Laser type: Multi-wavelength semiconductor (diode) laser platform
• Wavelengths: 450 / 635 / 980 / 1470 / 1940 nm (configuration dependent)
• Maximum output: Up to 30 W+
• Emission modes: CW · single pulse · repeat pulse
• Pulse width: 25 µs – 10 s
• Repetition rate: 0.05 Hz – 50 kHz
• Delivery: SMA905 fiber interface; contact fibers 200 / 400 / 600 / 1000 µm; non-contact tips
• Interface: 11.6" Android smart touchscreen
• Safety: Emergency laser stop · mechanical safety shutter · Class 4
• Power supply: 100 – 240 V, 50 – 60 Hz, 350 VA
• Weight: ~15 kg (portable console)
