Description
- Proline cabinet design
Strong body and front made from melamine
board incl. a 2 mm thick protection layer
and ABS edge strip, scratch- and waterproof.
Hygienic construction by smooth surfaces,
integrated formfitted hinges, double pressed
body with sealed and screwless connections
to perform reliability and durable function.
- Decor:
Body and edge: light gray (U112PE)
Fronts and edges: atoll blue (U125PE)
- carriage with bumper protection function
polyethylene, all of a piece
color: light gray
- 4 special designed swivel castors, 2 with brake
wheel diameter 125 mm
tread: thermoplastic rubber, gray non-marking
ball bearing
caster housing: polyamide
- Cart dimensions: approx. 821 x 584 mm (W x D)
working height: approx. 1116 mm
.
- Left side one push bar (PXSB589)
made of stainless steel
Backside: accommodation for overbridge norm rail
.
Cabinet design from top to bottom:
- 1 cabinet with two folding doors
height approx. 896 mm (14 HE)
with bow handle (stainless steel look)
left door with aluminium door strip
Top section:
- 1 middle separation panel (9,5 HE)
Left and right side:
- equipped with Hammerlit tray-panels
to accommodate ISO-trays 300 x 400 mm
or shelves 300 x 400 mm (FB1204000300)
Base (full width):
- 1 pullout frame (AR 64 ULF)
to accommodate ISO-trays 600 x 400 mm
pullout frame height adjustable on grid strips
(trays or shelves to be ordered separately)
