Laundry linen trolley W494L

with foot pedalwith handle2-bag

Overview
Laundry collector with hinge bearing and stainless steel frame. Designed to accept laundry bags with clamping rings and to accommodate a hinge cover (DT 80 to DT 88). Hinge cover sold separately.

Key features

• Available in versions with 2 or 4 rectangular clamping rings (model dependent)
• Includes adhesive clamping ring HR 2000
• Includes hinge lower part made of break-resistant plastic with integrated wall bumper for mounting hinge cover
• Frame material: stainless steel; all tube connections seamless welded
• Push handle and 2 stainless steel hooks (model W494L)
• 4 bump-stop discs (SP 32) and 4 swivel castors, 2 with double brake (model W494L)
• Wheel diameter: 75 mm
• Tires: full rubber, grey, non-marking

Product identification

• Item No.: W265L (2 rectangular clamping rings)
• Item No.: W494L (4 rectangular clamping rings)
• Hinge covers (DT 80 to DT 88) sold separately

Technical specifications

• Frame material: stainless steel
• Tube connections: seamless welded
• Clamping rings: 2 or 4 rectangular rings, depending on model
• Adhesive clamping ring: HR 2000
• Hinge lower part: break-resistant plastic with integrated wall bumper
• Compatible hinge covers: DT 80 to DT 88 (not included)
• Castors: 4 swivel castors, Ø 75 mm
• Tires: full rubber, grey, non-marking
• Dimensions W265L (WxDxH): approx. 670 x 480 x 950 mm
• Dimensions W494L (WxDxH): approx. 1000 x 700 x 950 mm
