Electric patient floor lift D80

battery-operatedportablefolding

Overview
The D80 patient transfer lift by INTCO Medical is designed for assisted transfers in clinical and care environments. It features an adjustable seat-to-floor height, electric lifting with battery backup and a steel powder-coated frame. Intended for use by trained caregivers; product selection should consider the intended user profile, local safety regulations and procurement standards before purchase.

Key features

• Frame: Steel with powder coating
• Seat to floor height: 420 mm–570 mm
• Total length: 730 mm
• Total width: 560 mm
• Total height: 810 mm
• Folded/dismantled dimensions: 360 mm × 560 mm × 680 mm
• Leg/frame height: 900 mm
• Supply voltage: 24 V
• Lifting range: 150 mm
• Battery capacity: 24 V 4.4 Ah
• Weight capacity: 120 kg
• Total weight: 35 kg

Product Parameters
Total Length(mm) | Total Width(mm) | Total Height(mm) | Supply Voltage | Lifting Range(mm) | Battery Capacity | Weight Capacity(kg) | Total Weight(kg) | Carton Size(cm)
730mm | 560mm | 810mm | 24V | 150mm | 24V4.4Ah | 120kg | 35kg | 60*43*76

Characteristics / Technical specifications

• Model: D80
• Frame material and finish: Steel with powder coating
• Seat to floor height: 420 mm–570 mm
• Total length: 730 mm
• Total width: 560 mm
• Total height: 810 mm
• Folded/dismantled dimensions (L×W×H): 360 mm × 560 mm × 680 mm
• Leg height / frame height: 900 mm
• Supply voltage: 24 V
• Lifting range: 150 mm
• Battery capacity: 24 V 4.4 Ah
• Weight capacity: 120 kg
• Total weight: 35 kg
• Carton size: 60 × 43 × 76 cm
