Multipurpose radiography X-ray generator Gemini 5

for fluoroscopyfloor-mountedwith power supply

Overview
Gemini 5 is a 5 kW integrated X-ray source with a rotating anode X‑ray tube, engineered for mobile C‑arm systems. It delivers continuous X‑ray output for fluoroscopy, fixed pulse‑width exposures for radiography, and supports pulsed X‑ray operation up to 30 fps for dynamic flat‑panel detector integration.

Features

• Compact integrated design with rotating‑anode tube
• Oil‑immersed housing integrating the X‑ray tube and high‑voltage components
• Support for multiple tube‑insert configurations
• High‑frequency inverter power supply
• Continuous and pulsed modes, pulsed operation up to 30 fps
• RS232 and CAN serial communication interfaces
• Windows‑based service GUI for diagnostics and configuration

Technical specifications

• Rated power: 5 kW
• Tube type: rotating anode X‑ray tube
• Supported modes: continuous fluoroscopy, fixed pulse‑width radiography, pulsed up to 30 fps
• Designed for integration with mobile C‑arm systems and dynamic flat‑panel detectors
• Cooling/integration: oil‑immersed housing combining tube and high‑voltage components
• Electrical: high‑frequency inverter
• Configuration: multiple tube‑insert options
• Interfaces: RS232 and CAN
• Service: Windows‑based GUI tool for diagnostics and configuration
