Slide dryer HistoCore

Overview
The HistoCore Slide Dryer is a compact accessory for drying and handling histology slides. It is designed to integrate with the HistoCore Water Bath M to allow flexible laboratory layouts and centralized power distribution.

Key features

• Compact footprint suitable for constrained bench spaces.
• Slide capacity: 30 slides to support medium-throughput workflows.
• Black drying rack background for improved ribbon visibility during slide handling.
• 45° angled heated rack for straightforward slide placement and retrieval.
• Direct connection to HistoCore Water Bath M; no separate power supply required.
• One HistoCore Water Bath M can supply power to up to two slide dryers.

Technical specifications

• Instrument dimensions (W x D x H): 200 x 280 x 98 mm
• Packaging dimensions (W x D x H): 415 x 395 x 215 mm
• Operating temperature: up to 75 °C
• Heating plate angle: 45°
• Slide rack capacity: 30 slides

Compatibility and usage

• The HistoCore Slide Dryer is an accessory that must be connected to a HistoCore Water Bath M to operate.
• Designed to optimize slide handling in histology workflows and to be positioned adjacent to the water bath for efficient layout.
