ield Of View - 140°
Direction Of View - Forward View
Depth Of Field - 3-100mm
Optical Technology mBLU - mBLU mode 1
Distal End Outer Diameter - 9.8mm
Insertion Tube Outer Diameter - 9.8mm
Distal End Enlarged
Air/Water Nozzle
Illumination LEDs (W)
Objective Lens
Instrument Channel Outlet
Working Length
L: 3000mm
I: 1400mm
S: 1055mm
Channel Inner Diameter - 2.8
Minimum Visible Distance - 3mm from the distal end
Angulation Range -
UP 180°
DOWN 140°
RIGHT 120°
LEFT 120°
