Field hospital bed YZ07-B

manualTrendelenburgheight-adjustable

Short Description
Deployable field hospital bed designed for emergency response and temporary medical facilities. The bed features an adjustable frame with head, leg and height adjustments, and can accommodate accessories such as side rails, IV poles and storage compartments. It is intended for rapid setup in field conditions and for use by first responders, disaster relief and remote medical teams.

Main Features

• Mobile critical care configuration for use in field hospitals and emergency units
• Rapid deployment: single-operation folding/unfolding in approximately 60 s
• Adjustable positions: head angle 0°–70°, leg positions 0°/30°/40° (±2°), Trendelenburg/reverse 0°/8° (±2°)
• Load capacity: static test up to 240 kg
• Compact transport size when folded and optional accessories compatible

Specifications

• Deployment/folding time: 60 s for a single operation
• Back angle: 0°–70°
• Leg angle: 0° / 30° / 40° (±2°)
• Trendelenburg/reverse Trendelenburg: 0° / 8° (±2°)
• Static load-bearing test: 240 kg
• Mattress dimensions: 1940×730×60 mm (size can be customised)
• Unfolded size: 2000×800×500/700 (±10) mm
• Folded size: 1015×800×215 (±10) mm
• Weight: ≤36 kg (without optional accessories)
