X-ray film printer 366-5

Overview
The 366-5 is a dry inkjet medical film printer designed for direct DICOM printing in clinical environments. It supports black-and-white and color PET film output, uses roll-fed media to enable long-format and whole-body prints, and integrates with free DICOMPrint software for PACS workflows.

Key features

• Direct DICOM printing via complimentary DICOMPrint software
• Supports black-and-white and color PET film
• High-speed roll-fed inkjet printing with automatic cut-to-size output
• Roll media prevents film sticking and enables long-format/whole-body printing
• Ink system: 5 ink tanks; cartridges available in 130 ml or 300 ml
• Connectivity: High-speed USB, wired LAN, Wi‑Fi

Product Specification
Model: 366-5
Spatial resolution: 2400x1200 dpi
Contrast resolution: 14 bits
Media type: Dry inkjet film (PET)
Media size: 8x10in (20x25cm), 10x12in, 11x14in, 14x14in, 14x17in (35x43cm), A4, A3
Film supply: Roll
Media output: Automatic cut according to print size
Supply capacity: 8x10in — 260 sheets/roll; 14x17in — 125 sheets/roll
Film loading: Daylight film loading
Maximum width: 17 inch (approx. 43 cm)
Throughput: 8x10in — up to 120 sheets/hour; 14x17in — up to 40 sheets/hour
Print color: Black or color
Ink tanks: 5
Ink cartridges: 130 ml or 300 ml
Power: 100–240V, 50/60Hz
Network: High-speed USB, Wired LAN, Wi‑Fi
Dimensions (W×D×H): 982×748×439 mm
Weight: 41 kg

Technical specifications

• Model: 366-5
• Spatial resolution: 2400x1200 dpi
• Contrast resolution: 14 bits
• Media type: Dry inkjet film (PET)
• Supported sizes: 8x10in, 10x12in, 11x14in, 14x14in, 14x17in, A4, A3
• Maximum width: 17 inch
• Throughput: up to 120 sheets/hour (8x10in); 40 sheets/hour (14x17in)
• Print color: Black or color
• Ink system: 5 tanks; cartridges 130 ml or 300 ml
• Power: 100–240V, 50/60Hz
• Connectivity: High-speed USB, Wired LAN, Wi‑Fi
• Dimensions: 982×748×439 mm
• Weight: 41 kg
