Mammography X-ray film printer MDST-24

Product Overview
MDST-24 is a compact medical thermal film printer developed for radiology departments and imaging centers. It delivers 508 dpi spatial resolution and 14-bit contrast resolution on dry thermal film, supporting both general radiology and mammography hardcopy needs.

Key Features

• 508 dpi spatial resolution for diagnostic-quality hardcopies
• Automatic one-key calibration and adaptive imaging to preserve consistent image quality
• High operational stability with simplified mechanical design to reduce downtime and maintenance
• Support for mammography printing and general radiology applications
• Compact footprint with two media sizes available online to optimize space and logistics

Product Specification
Model: MDST-24
Spatial resolution: 508 dpi
Contrast resolution: 14 bits
Media type: Dry thermal film
Media sizes supported: 8×10 in, 10×12 in, 11×14 in, 14×17 in
Film trays: 2 supply trays and 2 output trays
Supply tray capacity: 100 sheets per tray
Film loading: Daylight film loading
Density adjustment: Automatic
Throughput: 8×10 in — 90 sheets/hour; 14×17 in — 65 sheets/hour
Startup time: approx. 3 minutes at 25°C
Storage: 32 GB hard disk; Memory: 4 GB
Power: 100–240 V, 50/60 Hz; Power consumption: 400 VA
Dimensions (W×D×H): 600×500×465 mm
Weight: 51 kg

Product Description
The MDST-24 is a high-performance thermal imager optimized for clinical environments where reliable, consistent film hardcopies are required. Its 508 dpi resolution and 14-bit contrast handling provide the detail necessary for diagnostic review, while automatic calibration and density control simplify operation for radiology staff. Dual supply trays and daylight loading accelerate film handling and reduce interruptions in busy workflows.

Characteristics / Technical specifications

• Model: MDST-24
• Spatial resolution: 508 dpi
• Contrast resolution: 14 bits
• Media type: Dry thermal film
• Supported media sizes: 8×10 in, 10×12 in, 11×14 in, 14×17 in
• Film trays: 2 supply trays, 2 output trays
• Supply tray capacity: 100 sheets each
• Film loading: Daylight loading
• Density adjustment: Automatic
• Throughput: up to 90 sheets/hour (8×10 in); 65 sheets/hour (14×17 in)
• Startup time: approx. 3 minutes at 25°C
• Storage: 32 GB hard disk; Memory: 4 GB
• Power: 100–240 V, 50/60 Hz; Consumption: 400 VA
• Dimensions (W×D×H): 600×500×465 mm
• Weight: 51 kg
