Laboratory freezer C20V10C1EVO
medicalupright1-door

Laboratory freezer - C20V10C1EVO - SMEG Instruments - medical / upright / 1-door
Laboratory freezer - C20V10C1EVO - SMEG Instruments - medical / upright / 1-door
Add to favorites
Compare this product
Go to the SMEG Instruments website for more information

Characteristics

Applications
laboratory, medical
Configuration
upright
Number of doors
1-door
Power source
electric
Other characteristics
with natural refrigerant, with drawer, stainless steel
Capacity

100 l
(26.42 gal)

Temperature range

Max.: -10 °C
(14 °F)

Min.: -25 °C
(-13 °F)

Width

60 cm
(23.6 in)

Depth

60 cm
(23.6 in)

Height

85 cm
(33.5 in)

Number of decibels

45 dB

Description

Intended use
  • Instrument solutions: Life Science; Health Care
  • Life Science sector: Laboratory; Pharmaceutical; Petrochemical industry; Food industry; Small laboratories
  • Health Care sector: Sterilization units; Washing rooms; Care homes; Hospital pharmacy; Analytical laboratory

Type
Freezer

Main features
  • Door type: Solid
  • Capacity: 100 L
  • Temperature range: -10 / -25 °C
  • Datalogger: Yes
  • Lock: Standard
  • Side pass-through port: Optional
  • Backup battery for alarm acquisition unit: Optional
  • Clean contact for remote alarm: Standard
  • Insulation: 60 mm
  • Evaporation: Static
  • Refrigerant gas: R290
  • CFC-free: Yes
  • Internal lighting: LED

Interface and alarms
  • Display: 7" color LED touchscreen (800x480) with real-time temperature graph
  • WiFi connectivity: Yes, with real-time cloud connection
  • Alarm indicator on display: Yes
  • Audible alarm: Yes
  • Visual alarm: Yes
  • USB port: Yes

Construction
  • Door: Solid
  • Interior chamber material: Stainless steel with Scotch-Brite finish
  • External structure material: Hot-dip galvanized anti-corrosion sheet coated with white PVC film
  • Number of doors: 1
  • Casters: 4
  • Feet: 2
  • Number of compressors: 1

Performance / Energy label
  • Noise level: 45 dBA

Electrical connection
  • Supply voltage: 230V, 50Hz
  • Plug: (F;E) Schuko

Logistics information
  • External dimensions: 60 x 60 x 85 cm
  • Available version: 60 Hz version

Equipment and options
  • Included accessories: 2 drawers standard
  • Optional: BTEVO (Buffer battery - EVO series)

Features / Technical specifications
  • Model: C20V10C1EVO
  • Type: Freezer
  • Capacity: 100 L
  • Temperature range: -10 / -25 °C
  • Refrigerant gas: R290
  • Insulation: 60 mm
  • Evaporation: Static
  • Datalogger: Yes
  • Lock: Standard
  • Side pass-through port: Optional
  • Backup battery for alarm acquisition unit: Optional
  • Clean contact for remote alarm: Standard
  • Internal lighting: LED
  • Display: 7" touchscreen (800x480) with temperature graph
  • WiFi: Yes (real-time remote cloud)
  • Alarms: visual and audible; alarm indicator on display
  • USB port: Yes
  • Noise level: 45 dBA
  • Voltage: 230V, 50Hz
  • Plug: (F;E) Schuko
  • Interior material: Stainless steel (Scotch-Brite)
  • External structure: Hot-dip galvanized sheet coated in white PVC
  • Doors: 1
  • Casters: 4; Feet: 2
  • Number of compressors: 1
  • External dimensions: 60 x 60 x 85 cm
  • Included equipment: 2 drawers
