Dental micromotor control unit DIL-01T

brushless electricfoot-operatedwith LED light

Brushless Electric Internal Irrigation Micromotor Brand TEALTH Product origin CHINA Delivery time 3-5 DAYS Supply capacity 10000 PCS Order code: DIL-01T Dental Micro Motor Brushless Electric Package Content: 1 set Micro Brushless optic motor and 1 pc user manual Product name: Tealth® brushless electric micromotor Order code: DIL-01T Parameter: Max rotation speed: 40,000r/min Noise: less than 60dB Torque: 3.4N.cm Weight: 2500g Irrigation: Internal irrigation Connector: ISO standard E-type Operation panel keys used： A.To press the power key press to start the motor operation, switch indicator light, and then press one stop, switch indicator light out. B.When the motor is running, the positive reverse indicator light is on when it is turning, showing green, press the positive reverse selection key, the motor is reversed, and the positive reverse indicator light is on, showing orange red. C.When running the motor again, the motor speed and rotation press the memory of the last operation. D.When using a bending head with different speed ratios, the speed displayed by the speed display window is the speed of the head; Press the speed ratio selection key, you can choose the speed ratio corresponding to the nose, and the corresponding indicator light is on.
