Universal operating table YK-OT500electricadjustable heighttilting
Add to favorites
Compare this product
Characteristics
- Applications
- universal
- Operation
- electric
- Features
- adjustable height, tilting
- Components
- with legrest
- Number of sections
- 3-section
- Power source
- 220V / 50Hz
- Total length
145 cm
(57.1 in)- Total width
60 cm
(23.6 in)
Description
Technical configuration
Detail
Technical specifications
- Length / Width: 1450 mm / 600 mm
- Elevation (min / max): 570 mm / 970 mm
- Trendelenburg: ≥22°
- Reverse Trendelenburg: ≥22°
- Back plate tilt: +45° / -5°
- Power supply: 220 V, 50 Hz, 1.1 kW
- Handle support ×2
- Foot support ×2
- Leg board ×1
- Waste container ×1
Detail
- Includes accessories listed above. Configured for standard surgical use with motorized height and tilt adjustments to support intraoperative positioning.
Technical specifications
- Model length: 1450 mm
- Model width: 600 mm
- Height range: 570 mm (lowest) to 970 mm (highest)
- Trendelenburg angle: at least 22°
- Reverse Trendelenburg angle: at least 22°
- Back plate tilt: +45° / -5°
- Electrical supply: 220 V, 50 Hz, 1.1 kW
- Accessories included: 2 handle supports, 2 foot supports, 1 leg board, 1 waste container
