Straight rehabilitation staircase Alter Step

with rampwith 2 handrails

Overview
«Alter Step» dynamic stair trainer is a dynamic simulator for musculoskeletal training and gait recovery after injuries, stroke, cerebral palsy and other neurological conditions affecting walking function.

Description
«Alter Step» combines a four-step stair with anti-slip coating and adjustable handrails. The stair height is electrically adjustable from 0 to 15 cm, enabling exercises from early rehabilitation stages. In the flat position (zero step height) the unit serves as parallel bars. Handrail height and width are adjustable to patient anthropometry. The device can be fitted with one or two wheelchair ramps (600 or 900 mm) to facilitate transfers. Suitable for rehabilitation departments, neuro and cardiac rehabilitation centres, clinics and nursing homes.

Key benefits

• Supports patient motivation and engagement in gait training
• Helps overcome the psychological barrier to making the first step
• Reduces therapist physical workload and supervision time
• Can be used for supervised or self-directed training

Modifications

• «Alter Step» dynamic stair trainer with two ramps (600 and 900 mm) — Technical specifications: Wheelchair ramp length, mm 600/900; Step height, cm 0 – 15; Power supply, V/Hz 220/50.
• «Alter Step» dynamic stair trainer with a long ramp (900 mm) — Technical specifications: Wheelchair ramp length, mm 600/900; Step height, cm 0 – 15; Power supply, V/Hz 220/50.
• «Alter Step» dynamic stair trainer with a short ramp (600 mm) — Technical specifications: Wheelchair ramp length, mm 600/900; Step height, cm 0 – 15; Power supply, V/Hz 220/50.

Technical specifications

• Wheelchair ramp length: 600 / 900 mm
• Step height adjustment range: 0 – 15 cm (electric drive)
• Four-step stair with anti-slip coating
• Combined device: handrails + stair unit
• Handrails: adjustable height and width
• Can be used flat (zero step height) as parallel bars
• Optionally equipped with one or two wheelchair ramps
• Intended use: rehabilitation after injuries, stroke, cerebral palsy, cerebrovascular and other neurological pathologies affecting gait
• Power supply: 220 V / 50 Hz
