Monopolar coagulation electrosurgical unit COMBI-PLUS
fulgurationcuttingmonopolar cutting

Monopolar coagulation electrosurgical unit - COMBI-PLUS - Alan Electronic Systems - fulguration / cutting / monopolar cutting
Monopolar coagulation electrosurgical unit - COMBI-PLUS - Alan Electronic Systems - fulguration / cutting / monopolar cutting
Monopolar coagulation electrosurgical unit - COMBI-PLUS - Alan Electronic Systems - fulguration / cutting / monopolar cutting - image - 2
Monopolar coagulation electrosurgical unit - COMBI-PLUS - Alan Electronic Systems - fulguration / cutting / monopolar cutting - image - 3
Add to favorites
Compare this product
Go to the Alan Electronic Systems website for more information

Characteristics

Features
monopolar coagulation, fulguration, cutting, monopolar cutting, coagulation, bipolar coagulation, desiccation, bipolar cutting, vessel-sealing
Medical procedure
laparoscopic surgery
Technology
high-frequency, plasma, HF
Options
with touchscreen
Cutting power

Min.: 0 W
(0 hp)

Max.: 400 W
(0.5 hp)

Coagulating power

Min.: 0 W
(0 hp)

Max.: 400 W
(0.5 hp)

Description

Overview
  • Advanced microcontroller-based electrosurgical generator for open and laparoscopic surgeries.
  • 5-inch LCD touch screen with feather-touch buttons for rapid parameter selection.
  • Supports 2 monopolar outputs, 1 bipolar output and 1 ligature socket compatible with hand- and foot-switches.
  • Compatible with standard monopolar and bipolar surgical accessories and ALAN’s capacitive patient plate with PPCM patient contact monitoring.
  • Automatic self-test at start-up and real-time HF leakage monitoring to ensure operational safety.


Key Features
  • Max. power output 400 W with multiple regulated cutting and coagulation modes.
  • Vessel sealing capability up to 7 mm and tolerance to 3× systolic/diastolic pressure.
  • Tissue monitoring technology measures impedance and dynamically adjusts HF output.
  • HF current leakage control keeps leakage below 10 µA.
  • 99+1 user-programmable memory presets and automatic restoration after power interruption.
  • Upgradeable: compatible with Argon Plasma Coagulation and Smoke Evacuator System.


Monopolar Cut Modes
  • Pure: 400 W @ 350 Ohms CF 1.5
  • Lapcut: 300 W @ 350 Ohms CF 1.5 Input
  • Blend: 250 W @ 350 Ohms (10 Levels) CF Variable
  • EndoCut: 300 W @ 350 Ohms (10 Levels) CF Varied


Monopolar Coagulation Modes
  • Spray: 120 W @ 350 Ohms CF 9.0
  • Fulgurate: 150 W @ 350 Ohms CF 7.5
  • Desiccate: 200 W @ 350 Ohms CF 3.0
  • Soft: 300 W @ 150 Ohms CF 1.5
  • Auto Desiccate: Monopolar Desiccate with Auto-Stop
  • Auto Soft: Monopolar Soft with Auto-Stop


Bipolar Cut Modes
  • LoCut: 120 W @ 100 Ohms CF 1.5
  • HiCut: 120 W @ 100 Ohms CF 1.5
  • ScalCut: 200 W @ 100 Ohms (5 Levels) CF 1.5


Bipolar Coagulation Modes
  • Cut/Standard: 120 W @ 100 Ohms CF 1.5
  • Macro/Force: 120 W @ 100 Ohms CF 1.5
  • Micro/Precise: 100 W @ 100 Ohms CF 1.5
  • Auto Micro: Bipolar Micro with Auto-Stop
  • Auto Start: Auto-Start, Auto-Stop


Input Supply
  • Input: 88-265V AC, 50/60 Hz
  • Power Consumption: 750VA Max
  • Input Fuse: 5A T
  • Output Control: Colour TFT Display with Touch Screen and push buttons in all modes
  • Max. Power Output: 400 Watts


Safety Standards
  • Basic construction and electromagnetic compatibility as per IEC 60601-1, IEC 60601-1-2 & IEC 60601-2-2


Classifications
  • Protection Class: I
  • MDD Class: IIb
  • Pollution Degree: II
  • Overvoltage Category: II
  • Unit Type: CF (all output ports CF type)
  • Electrical potential balancing: Connecting pin indicated by symbol
  • PER: 98
  • Dimensions: 335 mm (W) x 160 mm (H) x 395 mm (D)
  • Weight: Maximum 8.0 Kg


Operating Parameters
  • Ambient temperature: +10° C to +40° C
  • Relative humidity: 30% to 75% non-condensing
  • Atmospheric pressure: 700 to 1060 millibars


Transport and Storage
  • Ambient temperature: -30° C to +65° C
  • Relative humidity: 0% to 90% non-condensing
  • Atmospheric pressure: 500 to 1060 millibars


Technical specifications
  • Model: COMBI-PLUS
  • Manufacturer / Brand: ALAN Electronic Systems
  • Max Power Output: 400 W
  • Input Voltage Range: 88-265V AC, 50/60 Hz
  • Power Consumption: 750VA Max
  • Input Fuse: 5A T
  • Display: 5-inch LCD touch screen with feather touch buttons
  • Outputs: 2 Monopolar outputs, 1 Bipolar output, 1 Ligate socket (handswitch & footswitch compatible)
  • Patient Plate: Supports capacitive patient plate with PPCM contact monitoring and graphical representation
  • Tissue monitoring: Measures tissue impedance and dynamically varies HF output
  • HF leakage control: Supervises and controls leakage to less than 10 µA
  • Vessel sealing: Up to 7 mm vessel thickness; withstands 3× systolic/diastolic pressure
  • Memory: 99+1 user-programmable memory presets
  • Upgradability: Compatible with Argon Plasma Coagulation and Smoke Evacuator System
  • Dimensions & Weight: 335 x 160 x 395 mm; Max weight 8.0 Kg
