Bipolar cutting electrosurgical unit ALLIGATURE
bipolar coagulationmonopolar coagulationcoagulation

Bipolar cutting electrosurgical unit - ALLIGATURE - Alan Electronic Systems - bipolar coagulation / monopolar coagulation / coagulation
Bipolar cutting electrosurgical unit - ALLIGATURE - Alan Electronic Systems - bipolar coagulation / monopolar coagulation / coagulation
Bipolar cutting electrosurgical unit - ALLIGATURE - Alan Electronic Systems - bipolar coagulation / monopolar coagulation / coagulation - image - 2
Bipolar cutting electrosurgical unit - ALLIGATURE - Alan Electronic Systems - bipolar coagulation / monopolar coagulation / coagulation - image - 3
Add to favorites
Compare this product
Go to the Alan Electronic Systems website for more information

Characteristics

Features
bipolar cutting, bipolar coagulation, monopolar coagulation, coagulation, desiccation, monopolar cutting, cutting, vessel-sealing, fulguration
Medical procedure
laparoscopic surgery
Technology
HF, high-frequency
Options
with touchscreen
Cutting power

Max.: 400 W
(0.5 hp)

Min.: 120 W
(0.2 hp)

Coagulating power

Max.: 300 W
(0.4 hp)

Min.: 100 W
(0.1 hp)

Description

Short Description
  • Advance multiple microcontroller based generator for Open and Laparoscopic Surgeries.
  • 5-inch LCD touch screen display with intuitive interface, and additional feather touch buttons.
  • Intuitive User Interface facilitates easy program and modes selection with Seamless Operations.
  • Features 2 Monopolar, 1 Bipolar and 1 Ligate socket, for handswitch and footswitch activation.
  • Compatible with universal accessories used in Monopolar and Bipolar Surgical Applications.
  • Supports ALAN’s special Capacitive Patient Plate for maximum safety of the patients in surgeries.
  • PPCM feature monitors patient’s contact quality and provides real-time graphical representation.
  • “Self-Test” diagnoses at every START UP for Generator’s healthiness & operational integrity.
  • Automatically stops the power output and provides audio-visual indication during problem.
  • Multiple cutting modes with varied regulated wattages for smooth and precise skin incisions.
  • Can seal up to 7 mm of vessel thickness and withstand 3 times systolic and diastolic pressure.
  • 7 different ligation levels are programmed for different vessel size and varied tissue vascularity.
  • Isolated Monopolar and Bipolar outputs, eliminating the frequent need for switch overs.
  • HF power output can be adjusted using touch screen and handswitch pencil from sterile field.
  • Simultaneous monopolar coagulation for 2 surgeons via handswitch and footswitch pairing.
  • Tissue monitoring technology measures tissue impedance & dynamically varies the HF output.
  • System restores previous activated power settings when encountering power interruptions.
  • HF current leakage monitoring & controlling system supervises and controls it to less than 10 uA.
  • 99+1 user programmable memory to store & recall surgery preferences and details.
  • Upgradeable and compatible with Argon Plasma Coagulation & Smoke Evacuator System.

Monopolar Cut Modes
  • Pure: 400 W @ 350 Ohms CF 1.5
  • Lapcut: 300 W @ 350 Ohms CF 1.5
  • Blend: 250 W @ 350 Ohms (10 Levels) CF Variable
  • EndoCut: 300 W @ 350 Ohms (10 Levels) CF Varied

Monopolar Coagulation Modes
  • Spray: 120 W @ 350 Ohms CF 9.0
  • Fulgurate: 150 W @ 350 Ohms CF 7.5
  • Desiccate: 200 W @ 350 Ohms CF 3.0
  • Soft: 300 W @ 150 Ohms CF 1.5
  • Auto Desiccate: Monopolar Desiccate with Auto-Stop
  • Auto Soft: Monopolar Soft with Auto-Stop

Vessel Sealing
  • Ligate: 5 Levels CF 1.5
  • F-Ligate: 2 Levels CF 1.5

Bipolar Cut Modes
  • LoCut: 120 W @ 100 Ohms CF 1.5
  • HiCut: 120 W @ 100 Ohms CF 1.5
  • ScalCut: 200 W @ 100 Ohms (5 Levels) CF 1.5

Bipolar Coagulation Modes
  • Cut/Standard: 120 W @ 100 Ohms CF 1.5
  • Macro/Force: 120 W @ 100 Ohms CF 1.5
  • Micro/Precise: 100 W @ 100 Ohms CF 1.5
  • Auto Micro: Bipolar Micro with Auto-Stop
  • Auto Start: Auto-Start, Auto-Stop

Input Supply
  • Input: 88-265V AC, 50/60 Hz
  • Power Consumption: 750 VA Max
  • Input Fuse: 5A T
  • Output Control: Colour TFT Display with Touch Screen and Push buttons in all Modes
  • Max. Power Output: 400 Watts

Safety Standards
  • Basic Construction: As per IEC 60601-1, IEC 60601-1-2 & IEC 60601-2-2

Classifications
  • Protection Class: I
  • Mdd. Class: II b
  • Pollution degree Class: II
  • Overvoltage category Class: II
  • Unit Type: CF
  • All Outputs: Floating Output (All output ports are CF Type)
  • Electrical Potential Balancing: Connecting Pin and Indicated by Symbol
  • PER: 98
  • Dimension: 335 mm (W) x 160 mm (H) x 395 mm (D)
  • Weight: Maximum 8.0 Kg

Operating Parameters
  • Ambient temperature range: +10° C to +40° C
  • Relative humidity: 30% to 75% non-condensing
  • Atmospheric pressure: 700 millibars to 1060 millibars

Transport and Storage
  • Ambient temperature range: -30° C to +65° C
  • Relative humidity: 0% to 90% non-condensing
  • Atmospheric pressure: 500 millibars to 1060 millibars

Caractéristiques / spécifications techniques
  • Model name: ALLIGATURE
  • Manufacturer / Brand: ALAN
  • Max Power Output: 400 W
  • Input Voltage: 88-265V AC, 50/60 Hz
  • Power Consumption: 750 VA Max
  • Input Fuse: 5A T
  • Display: 5-inch LCD touch screen (Colour TFT) with push buttons
  • Monopolar outputs: 2 (isolated)
  • Bipolar outputs: 1 (isolated)
  • Ligate output: 1
  • Vessel sealing capability: up to 7 mm vessel thickness
  • HF leakage control: < 10 μA
  • User programmable memory: 99+1 slots
  • Compliance: IEC 60601-1, IEC 60601-1-2, IEC 60601-2-2
  • Dimensions (W x H x D): 335 x 160 x 395 mm
  • Weight: up to 8.0 Kg
