Sterilization cabinet 3162 CR

fixedhospitalwith hinged door

Product overview
Body in AlMg3 light alloy sheet, anodized (10 micron). Internal frame with 2 vertical sections made in anodized light alloy profiles and nylon fiberglass rails with stopping system. Useful rail width 302 mm suitable for metal containers placed on BLSFL3004 shelves or for polypropylene containers with lids (BGDNN…) without shelves.

Doors and sealing
Double-wing doors built in 2.5 mm bent sheet with continuous hinges. Doors open to 270° with an additional stop at 260° for tunnel disinfection. Vertical thumb-latch secures the door by hooking at top and bottom. EPDM gasket around the opening (doors, base and cover); central junction and corner design ensure airtight protection during transport outside sterile areas.

Handling and chassis
One push-handle on each short side. Non-twisting light-alloy bottom frame. Non-marking grey rubber bumpers on top and bottom. Two fixed and two swivelling wheels Ø 160 mm with super-elastic grey rubber ring, ball-bearings with waterproof plastic protection and stainless steel housings.

Capacity and rails
Rails carrying capacity: 20 kg. Maximum capacity: 8 sterile units 300 x 600 x 300 mm (h) or 8 polypropylene containers 530 x 325 x 200 mm (h).

Product data
Model: RH3162ON001
Description: Cupboard trolley for sterile containers, 2 vertical sections, capacity 8 STU
Internal dimensions: 877 x 630 x 1220 mm (h)
External dimensions: 977 x 710 x 1585 mm (h)
Capacity: 8 STU 300 mm (h) or 8 BGDNN70200B
Weight: 71 kg
Wheels diameter: 160 mm
Containers: DIN Norm
Vertical sections: 2

Technical specifications

• Material: AlMg3 light alloy sheet, anodized (10 micron)
• Internal frame: anodized light alloy profiles, 2 vertical sections
• Rails: nylon fiberglass rails with stopping system; useful width 302 mm; pitch 150 mm
• Rails carrying capacity: 20 kg
• Maximum capacity: 8 STU (300 x 600 x 300 mm h) or 8 polypropylene containers (530 x 325 x 200 mm h)
• Doors: double-wing, 2.5 mm bent sheet, continuous hinges, opening 270° with stop at 260°
• Door fastening: vertical thumb-latch hooking top and bottom
• Sealing: EPDM gasket around opening (doors, base, cover)
• Handles: one push-handle on each short side
• Bottom frame: non-twisting light-alloy frame
• Buffers: non-marking grey rubber bumpers on top and bottom
• Wheels: 2 fixed + 2 swivel, Ø 160 mm, super-elastic grey rubber, ball-bearings with waterproof plastic protection and stainless steel housings
• Weight: 71 kg
• Internal dimensions: 877 x 630 x 1220 mm (h)
• External dimensions: 977 x 710 x 1585 mm (h)
• Model code: RH3162ON001
