Mixing bag 3D-100L-0201

for pharmaceutical productsfor biological sampleslaboratory

Product overview
A 3D single‑use bag is a cuboidal fluid containment chamber manufactured by sealing multiple film sheets to form a multi‑layer assembly with an inert polyethylene (PE) fluid contact layer. Typical volumes for this product family range from 50 ml to 2000 ml, with common production sizes shown here at 100 L, 200 L and 500 L. Unassisted fill (UAF) designs are possible: bags expand and deploy in a supporting tank during filling with minimal operator intervention, facilitating sterile single‑use bioprocess workflows.

Standard sizes available

• Single‑use 2D and 3D storage assemblies for fluid mixing, handling, storage and transportation.
• Volume range: 50 ml to 2000 ml; examples in this listing: 100 L, 200 L, 500 L.
• Available configurations: 2‑port and 3‑port variants, multiple port materials and fitting types to match process requirements.

Application

• Single‑use bioprocessing and biotechnology applications (mixing, media preparation, storage, transport).
• High oxygen barrier options for oxygen‑sensitive fluids.
• Designed for integration into supporting tanks or containment systems.

Compliance and certification

• ISO 10993‑4 Hemolysis
• ISO 10993‑5 Cytotoxicity
• ISO 10993‑6 Implantation test
• ISO 10993‑10 Irritation and Sensitization tests
• ISO 10993‑11 Acute Systemic Toxicity test
• USP <85> Bacterial Endotoxins – LAL test
• USP <87> Biological Reactivity Test in Vitro
• USP <88> Biological reactivity testing, in vivo, class VI
• European Pharmacopoeia tests 3.1.5
• USP <661.1> Polyethylene Physicochemical Tests, Extractable Metals
• Assessment of plastic additives and extractables/leachables as required

Characteristics

• Multi‑layer film construction with an inert PE fluid contact layer.
• Low extractables and leachables profile; no animal‑derived components.
• Port materials: PCS (polymer) and TPE options; fittings: male insert + female plug, AseptiQuick G, end plugs, 1/4" female luer lock.

Size‑specific configurations and catalogue numbers
100L Bags
Drawing: 3D-Bag-100L-Drawing.jpg
Drawing | Description | Catalogue No.
Port 1: PCS tube with 3/8" male insert and female plug; Port 2: PCS tube with 3/8" male insert and female plug — 3D-100L-0201
Port 1: PCS tube with 3/8" AseptiQuick G; Port 2: PCS tube with 3/8" AseptiQuick G — 3D-100L-0202
Port 1: PCS tube with 3/8" end plug; Port 2: PCS tube with 3/8" end plug — 3D-100L-0203
Port 1: PCS tube with 1/2" male insert and female plug; Port 2: PCS tube with 1/2" male insert and female plug — 3D-100L-0204
Port 1: PCS tube with 1/2" AseptiQuick G; Port 2: PCS tube with 1/2" AseptiQuick G — 3D-100L-0205
Port 1: PCS tube with 1/2" End plug; Port 2: PCS tube with 1/2" End plug — 3D-100L-0206
Port 1: TPE tube with 3/8" male insert and female plug; Port 2: TPE tube with 3/8" male insert and female plug — 3D-100L-0207
Port 1: TPE tube with 3/8" AseptiQuick G; Port 2: TPE tube with 3/8" AseptiQuick G — 3D-100L-0208
Port 1: TPE tube with 3/8" End plug; Port 2: TPE tube with 3/8" End plug — 3D-100L-0209
Port 1: TPE tube with 1/2" male insert and female plug; Port 2: TPE tube with 1/2" male insert and female plug — 3D-100L-0210
Port 1: TPE tube with 1/2" AseptiQuick G; Port 2: TPE tube with 1/2" AseptiQuick G — 3D-100L-0211
Port 1: TPE tube with 1/2" End plug; Port 2: TPE tube with 1/2" End plug — 3D-100L-0212
Port 1: PCS 3/8" male insert + female plug; Port 2: PCS 3/8" male insert + female plug; Port 3: PCS 1/4" female luer lock + male plug — 3D-100L-0301
Port 1: PCS 3/8" AseptiQuick G; Port 2: PCS 3/8" AseptiQuick G; Port 3: PCS 1/4" female luer lock + male plug — 3D-100L-0302
Port 1: PCS 1/2" male insert + female plug; Port 2: PCS 1/2" male insert + female plug; Port 3: PCS 1/4" female luer lock + male plug — 3D-100L-0303
Port 1: PCS 1/2" AseptiQuick G; Port 2: PCS 1/2" AseptiQuick G; Port 3: PCS 1/4" female luer lock + male plug — 3D-100L-0304
Port 1: TPE 3/8" male insert + female plug; Port 2: TPE 3/8" male insert + female plug; Port 3: TPE 1/4" female luer lock + male plug — 3D-100L-0305
Port 1: TPE 3/8" AseptiQuick G; Port 2: TPE 3/8" AseptiQuick G; Port 3: TPE 1/4" female luer lock + male plug — 3D-100L-0306
Port 1: TPE 1/2" male insert + female plug; Port 2: TPE 1/2" male insert + female plug; Port 3: TPE 1/4" female luer lock + male plug — 3D-100L-0307
Port 1: TPE 1/2" AseptiQuick G; Port 2: TPE 1/2" AseptiQuick G; Port 3: TPE 1/4" female luer lock + male plug — 3D-100L-0308
Port 1: PCS 3/8" End plug; Port 2: PCS 3/8" End plug; Port 3: PCS 1/4" End plug — 3D-100L-0309
Port 1: PCS 1/2" End plug; Port 2: PCS 1/2" End plug; Port 3: PCS 1/4" End plug — 3D-100L-0310
Port 1: TPE 3/8" End plug; Port 2: TPE 3/8" End plug; Port 3: TPE 1/4" End plug — 3D-100L-0311
Port 1: TPE 1/2" End plug; Port 2: TPE 1/2" End plug; Port 3: TPE 1/4" End plug — 3D-100L-0312

200L Bags
Drawing: 3D-Bag-200L-Drawing.jpg
Drawing | Description | Catalogue No.
Port 1: PCS tube with 3/8" male insert and female plug; Port 2: PCS tube with 3/8" male insert and female plug — 3D-200L-0201
Port 1: PCS tube with 3/8" AseptiQuick G; Port 2: PCS tube with 3/8" AseptiQuick G — 3D-200L-0202
Port 1: PCS tube with 3/8" end plug; Port 2: PCS tube with 3/8" end plug — 3D-200L-0203
Port 1: PCS tube with 1/2" male insert and female plug; Port 2: PCS tube with 1/2" male insert and female plug — 3D-200L-0204
Port 1: PCS tube with 1/2" AseptiQuick G; Port 2: PCS tube with 1/2" AseptiQuick G — 3D-200L-0205
Port 1: PCS tube with 1/2" End plug; Port 2: PCS tube with 1/2" End plug — 3D-200L-0206
Port 1: TPE tube with 3/8" male insert and female plug; Port 2: TPE tube with 3/8" male insert and female plug — 3D-200L-0207
Port 1: TPE tube with 3/8" AseptiQuick G; Port 2: TPE tube with 3/8" AseptiQuick G — 3D-200L-0208
Port 1: TPE tube with 3/8" End plug; Port 2: TPE tube with 3/8" End plug — 3D-200L-0209
Port 1: TPE tube with 1/2" male insert and female plug; Port 2: TPE tube with 1/2" male insert and female plug — 3D-200L-0210
Port 1: TPE tube with 1/2" AseptiQuick G; Port 2: TPE tube with 1/2" AseptiQuick G — 3D-200L-0211
Port 1: TPE tube with 1/2" End plug; Port 2: TPE tube with 1/2" End plug — 3D-200L-0212
Port 1: PCS 3/8" male insert + female plug; Port 2: PCS 3/8" male insert + female plug; Port 3: PCS 1/4" female luer lock + male plug — 3D-200L-0301
Port 1: PCS 3/8" AseptiQuick G; Port 2: PCS 3/8" AseptiQuick G; Port 3: PCS 1/4" female luer lock + male plug — 3D-200L-0302
Port 1: PCS 1/2" male insert + female plug; Port 2: PCS 1/2" male insert + female plug; Port 3: PCS 1/4" female luer lock + male plug — 3D-200L-0303
Port 1: PCS 1/2" AseptiQuick G; Port 2: PCS 1/2" AseptiQuick G; Port 3: PCS 1/4" female luer lock + male plug — 3D-200L-0304
Port 1: TPE 3/8" male insert + female plug; Port 2: TPE 3/8" male insert + female plug; Port 3: TPE 1/4" female luer lock + male plug — 3D-200L-0305
Port 1: TPE 3/8" AseptiQuick G; Port 2: TPE 3/8" AseptiQuick G; Port 3: TPE 1/4" female luer lock + male plug — 3D-200L-0306
Port 1: TPE 1/2" male insert + female plug; Port 2: TPE 1/2" male insert + female plug; Port 3: TPE 1/4" female luer lock + male plug — 3D-200L-0307
Port 1: TPE 1/2" AseptiQuick G; Port 2: TPE 1/2" AseptiQuick G; Port 3: TPE 1/4" female luer lock + male plug — 3D-200L-0308
Port 1: PCS 3/8" End plug; Port 2: PCS 3/8" End plug; Port 3: PCS 1/4" End plug — 3D-200L-0309
Port 1: PCS 1/2" End plug; Port 2: PCS 1/2" End plug; Port 3: PCS 1/4" End plug — 3D-200L-0310
Port 1: TPE 3/8" End plug; Port 2: TPE 3/8" End plug; Port 3: TPE 1/4" End plug — 3D-200L-0311
Port 1: TPE 1/2" End plug; Port 2: TPE 1/2" End plug; Port 3: TPE 1/4" End plug — 3D-200L-0312

500L Bags
Drawing: 3D-Bag-500L-Drawing.jpg
Drawing | Description | Catalogue No.
Port 1: PCS tube with 3/8" male insert and female plug; Port 2: PCS tube with 3/8" male insert and female plug — 3D-500L-0201
Port 1: PCS tube with 3/8" AseptiQuick G; Port 2: PCS tube with 3/8" AseptiQuick G — 3D-500L-0202
Port 1: PCS tube with 3/8" end plug; Port 2: PCS tube with 3/8" end plug — 3D-500L-0203
Port 1: PCS tube with 1/2" male insert and female plug; Port 2: PCS tube with 1/2" male insert and female plug — 3D-500L-0204
Port 1: PCS tube with 1/2" AseptiQuick G; Port 2: PCS tube with 1/2" AseptiQuick G — 3D-500L-0205
Port 1: PCS tube with 1/2" End plug; Port 2: PCS tube with 1/2" End plug — 3D-500L-0206
Port 1: TPE tube with 3/8" male insert and female plug; Port 2: TPE tube with 3/8" male insert and female plug — 3D-500L-0207
Port 1: TPE tube with 3/8" AseptiQuick G; Port 2: TPE tube with 3/8" AseptiQuick G — 3D-500L-0208
Port 1: TPE tube with 3/8" End plug; Port 2: TPE tube with 3/8" End plug — 3D-500L-0209
Port 1: TPE tube with 1/2" male insert and female plug; Port 2: TPE tube with 1/2" male insert and female plug — 3D-500L-0210
Port 1: TPE tube with 1/2" AseptiQuick G; Port 2: TPE tube with 1/2" AseptiQuick G — 3D-500L-0211
Port 1: TPE tube with 1/2" End plug; Port 2: TPE tube with 1/2" End plug — 3D-500L-0212
Port 1: PCS 3/8" male insert + female plug; Port 2: PCS 3/8" male insert + female plug; Port 3: PCS 1/4" female luer lock + male plug — 3D-500L-0301
Port 1: PCS 3/8" AseptiQuick G; Port 2: PCS 3/8" AseptiQuick G; Port 3: PCS 1/4" female luer lock + male plug — 3D-500L-0302
Port 1: PCS 1/2" male insert + female plug; Port 2: PCS 1/2" male insert + female plug; Port 3: PCS 1/4" female luer lock + male plug — 3D-500L-0303
Port 1: PCS 1/2" AseptiQuick G; Port 2: PCS 1/2" AseptiQuick G; Port 3: PCS 1/4" female luer lock + male plug — 3D-500L-0304
Port 1: TPE 3/8" male insert + female plug; Port 2: TPE 3/8" male insert + female plug; Port 3: TPE 1/4" female luer lock + male plug — 3D-500L-0305
Port 1: TPE 3/8" AseptiQuick G; Port 2: TPE 3/8" AseptiQuick G; Port 3: TPE 1/4" female luer lock + male plug — 3D-500L-0306
Port 1: TPE 1/2" male insert + female plug; Port 2: TPE 1/2" male insert + female plug; Port 3: TPE 1/4" female luer lock + male plug — 3D-500L-0307
Port 1: TPE 1/2" AseptiQuick G; Port 2: TPE 1/2" AseptiQuick G; Port 3: TPE 1/4" female luer lock + male plug — 3D-500L-0308
Port 1: PCS 3/8" End plug; Port 2: PCS 3/8" End plug; Port 3: PCS 1/4" End plug — 3D-500L-0309
Port 1: PCS 1/2" End plug; Port 2: PCS 1/2" End plug; Port 3: PCS 1/4" End plug — 3D-500L-0310
Port 1: TPE 3/8" End plug; Port 2: TPE 3/8" End plug; Port 3: TPE 1/4" End plug — 3D-500L-0311
Port 1: TPE 1/2" End plug; Port 2: TPE 1/2" End plug; Port 3: TPE 1/4" End plug — 3D-500L-0312

Technical specifications / Characteristics

• Shape: 3D (cuboidal) bags manufactured by sealing multiple film sheets.
• Typical volumes: 50 ml to 2000 ml (examples listed: 100 L, 200 L, 500 L).
• Construction: multi‑layer film with inert PE fluid contact layer to minimise interactions.
• Materials: PE contact layer; PCS and TPE tubing options; no animal‑derived components.
• Ports and fittings: male insert + female plug, AseptiQuick G fittings, end plugs, 1/4" female luer lock; available in 2‑port and 3‑port configurations.
• Regulatory testing: ISO 10993 series, USP <85>, <87>, <88>, <661.1>, European Pharmacopoeia 3.1.5, extractables/metal testing as specified.
• Performance: designed for fluid mixing, handling, storage and transport in single‑use biotech processes; high oxygen barrier options available.
