Vaccine refrigerator TCW 2000 SDD

upright1-doorharsh environments

Overview

• Solar Direct Drive vaccine refrigerator and ice-pack freezer for cold chain storage. Gross volumes: Refrigerator 118 L; Freezer 42 L.
• Set temperatures: Freezer -25°C; Refrigerator +5°C.
• Vaccine storage capacity: 99 L. Ice-pack storage (0.6 L): 14.4 kg.
• Certifications: EMC directive 2014/30/EU; EU MDD Class I; Low voltage 2014/35/EU.
• Climate class: Temperate (+32°C). Energy source: Solar / DC (25V DC). Refrigerant: Natural R600a.

Resistance to harsh environment

• Designed to operate in tropical conditions (32°C to 43°C depending on model).
• Rotomoulded polyethylene body: rust-free and impact resistant.
• Humidity control to prevent condensation inside the cabinet.
• Warranty coverage: 10 years international manufacturer’s warranty and lifetime warranty against corrosion.

Ergonomic Design

• Replaceable, washable door gaskets for simplified maintenance.
• "Plug and play" installation for solar generators; direct-drive operation without battery or regulator.
• External temperature display and real-time web visualization for remote checks.
• Remote monitoring solution (RTMD) included for data logging and platform access.

Safety and traceability

• High-performance insulation: extended holdover time during periods of low or no sunlight.
• Silicone gaskets and lockable clasps to secure access.
• Audio-visual alarm system with remote transmission capability.
• Remote temperature monitoring with data logger and digital platform for traceability.

Product details (key data)
Gross volume: Refrigerator 118 L | Freezer 42 L
Vaccine storage capacity: 99 L
Ice-pack storage (0.6 L): 14.4 kg
Set temperature: -25°C (freezer) | +5°C (refrigerator)
Climate class (ambient): Temperate (+32°C)
Certifications: EMC directive 2014/30/EU | EU MDD Class I | Low voltage 2014/35/EU
External dimensions (HxWxD): 910 x 1270 x 780 mm
Net weight: 108 kg
Shipping weight: 161 kg
Supply voltage: 25V DC
Refrigerant type: Natural R600a
Materials: Polyethylene (rotomoulded body)
Remote monitoring: RTMD included (data logger & digital platform)
Autonomy: 85h 24min
Cool down time: 12h
Hold over time: 92h at +32°C
Energy consumption (stable running): 0.78 kWh / 24h at 32°C
Energy source: Solar / DC (direct drive, no battery/regulator required)
Freeze protection level: Grade A
Product type: Solar Direct Drive Vaccine Refrigerator & Ice-pack Freezer

Technical specifications

• Model: TCW 2000 SDD
• Gross volume: Freezer 42 L; Refrigerator 118 L (1.48 cu ft | 4.17 cu ft)
• Vaccine storage capacity: 99 L
• Ice-pack capacity (0.6 L): 14.4 kg
• Set temperatures: Freezer -25°C; Refrigerator +5°C
• Climate class: Temperate (operational at +32°C; some models up to +43°C)
• Certifications: EMC directive 2014/30/EU; EU MDD Class I; Low voltage 2014/35/EU
• Dimensions (HxWxD): 910 x 1270 x 780 mm
• Net weight: 108 kg; Shipping weight: 161 kg
• Supply voltage: 25V DC
• Refrigerant: Natural R600a
• Materials: Polyethylene (rotomoulded)
• Remote monitoring: RTMD included (data logger and digital platform)
• Autonomy (holdover): 85h 24min; Hold over time: 92h at +32°C
• Cool down time: 12h
• Energy consumption (stable running): 0.78 kWh / 24h at 32°C
• Energy source: Solar / DC (direct drive, no battery/regulator required)
• Freeze protection: Grade A
• Security features: Silicone gaskets, lockable clasps, audio-visual alarm with remote transmission
• Warranty: 10 years international manufacturer’s warranty and lifetime warranty against corrosion
