Vaccine refrigerator TCW 15R SDD

uprightruggedcorrosion-resistant

Short description
Solar Direct Drive vaccine refrigerator with 26.5 L gross volume, designed for reliable cold chain storage at +5°C.

• Set temperature: +5°C
• Vaccine storage capacity: 16 L
• Certifications: EMC directive 2014/30/EU | EU MDD Class I | Low voltage 2014/35/EU
• Freeze protection level: Grade A
• Climate class (ambient temperature range): Hot zone (+43°C)
• Energy source: Solar / DC

Resistance to harsh environment

• Engineered for tropical operation (32°C to 43°C depending on configuration)
• Rotomoulded polyethylene body: corrosion‑free and impact resistant
• Humidity control prevents internal condensation
• Manufacturer warranty: 10 years international plus lifetime corrosion warranty

Ergonomic design

• Replaceable, washable door gaskets for easy maintenance
• Plug-and-play installation of solar generators
• No battery or regulator required: simplified upkeep and lower lifecycle costs
• External temperature display and real-time web visualization

Safety and traceability

• High-performance insulation for extended holdover during low/no sunlight
• Silicone gaskets and lockable clasps ensure secure closure and restricted access
• Audio-visual alarm system with remote transmission capability
• Remote temperature monitoring solution included (data logger and digital platform)

Brochure
Vaccine cold chain brochure is available (PDF on the product page).

Technical specifications
Model: TCW 15R SDD
Gross volume: 26.5 L | 0.94 cu ft
Vaccine storage capacity: 16 L
Set temperature: +5°C
Climate class (ambient temperature range): Hot zone (+43°C)
Certifications: EMC directive 2014/30/EU | EU MDD Class I | Low voltage 2014/35/EU
External dimensions (HxWxD): 950 x 730 x 730 mm | 37.40 x 28.74 x 28.74 in
Net weight: 69.5 kg | 153.22 lb
Shipping weight: 94 kg
Supply voltage: 25V DC
Refrigerant type: Natural R600a
Materials: Polyethylene
Remote monitoring: RTMD included
Autonomy: 81h 52min
Cool down: 36h
Hold over time: 123h30 min at 32°C; 87h48 min at 43°C
Energy consumption /24h (stable running): 0.43 kWh/24h at 43°C
Energy source: Solar / DC
Freeze protection level: Grade A
Product type: Solar Direct Drive Vaccine Refrigerator

Technical specifications (list)

• Model: TCW 15R SDD
• Gross volume: 26.5 L
• Vaccine storage capacity: 16 L
• Set temperature: +5°C
• Climate class: Hot zone (+43°C)
• Certifications: EMC 2014/30/EU; EU MDD Class I; Low voltage 2014/35/EU
• External dimensions (HxWxD): 950 x 730 x 730 mm
• Net weight: 69.5 kg
• Shipping weight: 94 kg
• Supply voltage: 25V DC
• Refrigerant: Natural R600a
• Materials: Polyethylene
• Remote monitoring: RTMD included
• Autonomy: 81h 52min
• Cool down time: 36h
• Hold over time: 123h30 min at 32°C; 87h48 min at 43°C
• Energy consumption (stable): 0.43 kWh/24h at 43°C
• Energy source: Solar / DC
• Freeze protection level: Grade A
