Digital capillaroscope MEDLW4N5 Pro

computer-basedcamera-basedwith USB connection

Product description
The CapillaryScope 500 Pro Wireless (MEDLW4N5 Pro) is a compact nailfold capillaroscope designed for clinical examination of the microcirculation under the fingernail. It captures and stores detailed nailfold capillaroscopy images at 500x magnification for diagnostic review and documentation.

Key features

• 500x optical magnification for detailed microcapillary observation
• Wireless connectivity (Wi‑Fi) and USB 2.0 interface for flexible deployment
• Built-in switchable linear polarizer to reduce glare when using contact oil or water
• Glass lens with anti-reflection coating and 8 white LEDs with on/off control
• Automatic Magnification Reading (AMR) and Microtouch sensor for repeatable imaging
• Certified as Medical Device Class 1 under EU MDR 2017/745; includes required software

Specification (table)
Lighting - Light/ LED type: White
Lighting - Number of LEDs: 8
Lighting - LED on/off switchable: Yes
Lighting - Infrared filter: IR cut-filter >650 nm
Lighting - Diffuser available: No
Lighting - Polarizer: Yes, linear
Optics - Magnification: 500x
Optics - Lens type: Glass with anti-reflection coating
Sensor - Sensor type: CMOS
Sensor - Resolution: 1.3 Megapixel (1280x1024)
Sensor - Maximum frame rate: 30 fps
Compatibility - Interface: USB 2.0
Compatibility - Operating system: Windows 7, 8, 10 & 11, MacOS 10.9 and up
Compatibility - Software: DinoCapture 2.0 (Windows) cable + wireless, DinoXcope (Mac OS) cable only, DinoConnect wireless only
Compatibility - Supported image formats (Windows): BMP, GIF, PNG, JPG, TIF, RAS, PNM, TGA, PCX, MNG, WBMP, JP2, JPC, PGX
Compatibility - Supported video formats (Windows): WMV, FLV, SWF
Compatibility - Supported image formats (MacOS): JPEG, PNG
Compatibility - Supported video formats (MacOS): MOV
Compatibility - Imaging standards: DirectShow, UVC
Compatibility - Wifi: Yes
Housing - Housing material: Composite/plastic housing
Housing - Magnification lock: Yes
Housing - Dimensions: 10.5cm (L) x 3.2cm (D)
Housing - Weight: 105 g
Housing - Cable length: 1.8m
Features - Special feature: Automatic Magnification Reading (AMR)
Features - Measurement: No
Features - Calibration: No
Features - Microtouch sensor: Yes
Information - Package contents: Microscope, carry pouch, software CD, user manual, N3C-N- CapillaryScope cap
Information - Warranty information: 2 years European warranty
Information - Regulatory approval: Medical Device Class 1 – Medical Devices Regulation (EU) 2017/745
Information - Price range: €900,00 - €1100,00

Technical specifications

• Manufacturer: Dino-Lite
• Model: CapillaryScope 500 Pro (MEDLW4N5 Pro)
• Intended use: Nailfold capillaroscopy for microcirculation assessment
• Magnification: 500x
• Sensor: CMOS, 1.3 Megapixel (1280x1024)
• Max frame rate: 30 fps
• Illumination: White LEDs, 8, on/off switchable
• Infrared filter: IR cut-filter >650 nm
• Polarizer: Linear, switchable
• Lens: Glass with anti-reflection coating
• Interface: USB 2.0; Wi‑Fi supported
• OS compatibility: Windows 7/8/10/11, MacOS 10.9+
• Imaging standards: DirectShow, UVC
• Housing material: Composite/plastic
• Magnification lock: Yes
• Dimensions: 10.5 cm (L) x 3.2 cm (D); Weight: 105 g
• Cable length: 1.8 m
• Special features: Automatic Magnification Reading (AMR), Microtouch sensor
• Package includes: Microscope, carry pouch, software CD, user manual, CapillaryScope cap N3C-N
• Warranty: 2 years (Europe)
• Regulatory: Medical Device Class 1 (EU MDR 2017/745)
• Price range indicative: €900,00 - €1100,00
