4K OR video system

3840 × 2160MP4OEM

Overview Engineered for surgical visualization at true 4K, this camera control unit (CCU) delivers high-resolution endoscopic imaging for OEM and private-label programmes. The system combines 3840×2160 capture with intelligent glare control, vascular enhancement and scope-aware tuning to support a wide range of rigid and semi-rigid endoscopes.

Key highlights

• True 4K visualization at 3840 × 2160
• Intelligent glare control and moiré suppression
• Vascular detail enhancement and image tuning
• Scope-optimized imaging for rigid/semi-rigid scopes
• 4K@60FPS MP4 recording and JPEG still capture
• Medical-grade 7-inch capacitive touchscreen
• IPX7 ingress protection and 3.0 m highly flexible cable

Specifications (table) System Resolution: 3840 × 2160 UHD
Output Frame Rates: 60 Hz
Primary Video Output: 4K HDMI 2.0 ×1
Auxiliary Video Output: 3G-SDI ×1, DVI-D ×1
Display: 7-inch medical-grade capacitive touchscreen
Recording & Capture: 4K@60FPS (MP4) / JPEG stills
Primary Controls: AWB, Record, Snapshot, Freeze
Advanced Controls: Scope controls, image controls, vascular enhancement
Effective Pixels: 3840 × 2160 (UHD)
Minimum Illumination: ≤ 0.5 Lux
SNR: >56 dB
Electronic Zoom: Multi-level digital zoom
Controls: 4 programmable buttons
Ingress Protection: IPX7
Cable: 3.0 m highly-flexible
Optical Mount: Compatible with rigid and semi-rigid endoscopes

Technical specifications

• Camera control unit for endoscopic surgery (CCU)
• True 4K capture and output (3840×2160)
• 4K@60FPS MP4 recording, JPEG stills
• 7-inch medical capacitive touchscreen for on-board review
• Multiple outputs: HDMI 2.0, 3G-SDI, DVI-D
• Advanced image processing: glare control, moiré suppression, vascular enhancement
• Low-light sensitivity: ≤ 0.5 Lux; SNR >56 dB
• Ingress protection IPX7 and 3.0 m flexible cable
• Compatible optical mount for rigid/semi-rigid scopes
