Medical video camera 10X

for surgical lightsfor open surgerysurgical

Series
Celesta Series

Product overview
Integrated surgical camera aligned with the light axis for shadow-free Full HD documentation (10X or 30X optical zoom). The camera captures high-resolution, true-colour images and videos directly from the illuminated surgical field. Precisely aligned with the light axis, it supports clear, shadow-free visualisation for recording, live viewing, and teaching in clinical environments.

Key features

• Full HD Resolution: Capture 720p and 1080p HD video with clear detail for procedure documentation.
• Precise Light Axis Alignment: Alignment with the light axis minimizes shadows within the surgical field.
• High Optical Zoom: Available in 10X or 30X optical zoom configurations with digital zoom enhancement.
• True-Colour Imaging: CMOS sensor technology delivers accurate colour reproduction for tissue differentiation.
• Dual Output Options: SDI and HDMI outputs for connection to recording systems, operating-room displays, and teaching equipment.
• Seamless Integration: Designed for continuous recording and live viewing without disrupting surgical workflow.

Ordering information (product variants)

• 10X Full HD Camera
• 30X Full HD Camera

Product specifications (table)
Parameter | 10X Full HD Camera | 30X Full HD Camera
Image Sensor | 1/2.8-type CMOS (Progressive Scan) | 1/2.8-type CMOS (Progressive Scan)
Effective Number of Pixels | 5.14 M Pixels | 2.13 M Pixels
Signal System (HD) | 720p, 1080p | 720p, 1080p
Video Output | SDI, HDMI | SDI, HDMI
Zoom | 10X Optical, 16X Digital | 30X Optical, 12X Digital
White Balance | Auto, Manual, One push | Auto, Manual, One push
Exposure, Focusing System | Auto, Manual | Auto, Manual
Signal to Noise Ratio | More than 50 dB | More than 50 dB
Aperture | F 1.8 - 3.4 | F 1.6 - 4.7
Power | 4.4 W | 5 W

Technical characteristics

• Image Sensor: 1/2.8-type CMOS (Progressive Scan)
• Effective Number of Pixels: 5.14 M (10X) / 2.13 M (30X)
• Signal System (HD): 720p, 1080p
• Video Output: SDI and HDMI
• Zoom: 10X Optical with 16X Digital (10X model); 30X Optical with 12X Digital (30X model)
• White Balance: Auto, Manual, One push
• Exposure & Focusing: Auto, Manual
• Signal to Noise Ratio: >50 dB
• Aperture: F1.8–3.4 (10X) / F1.6–4.7 (30X)
• Power Consumption: 4.4 W (10X) / 5 W (30X)
