Veterinary dental micromotor EL-ELC02

dentalveterinaryfor equines

The Equus Liberty Connect motor (EL-ELC02) is a wireless electric motor designed for equine dentistry and veterinary use, combining mobility with integrated Bluetooth connectivity for the Connect range.

Key features and benefits

• Compact, lightweight design for mobility and easy handling
• Wireless operation (battery or transformer powered) for fully mobile working
• Very quiet operation while delivering high performance at low speeds
• Bluetooth connectivity to communicate and be managed with other Connect devices via an Android app
• All functions accessible from a phone or tablet (Android application); connected devices can be linked for coordinated operation

Motor details

• High-efficiency electric motor with extremely quiet operation
• Optimised performance at very low speeds; up to 17,000 RPM when using the wireless foot pedal with appropriate power source
• Integrated control screen for settings and operation (includes battery gauge)
• Digital management via DSP microprocessor
• Electronic clutch for protection of the horse's mouth and increased equipment life
• Electronically controlled burr power and speed regulation with energy optimisation
• Bidirectional rotation (operates in both directions)
• Start/stop and direction selection available
• Stepwise speed variation during operation
• Optional control of a water pump (start/stop)
• Shock-resistant aluminium case that assists heat evacuation
• Available with multiple coupling options to fit different handpieces/connectors

Power supply and maximum speed summary

• Without a wireless foot pedal: maximum speed = 10,000 rpm (regardless of power supply)
• With a wireless foot pedal: maximum speed depends on power supply — 13,000 rpm with VM4 battery; 17,000 rpm with V4A battery or transformer
• V4A battery and transformer are supplied as 1 piece; VM4 battery is supplied as 2 pieces

Available supports / carrying options

• Hanging ring — to hang the motor directly (suitable for trolley use); an extension lead is needed to place the battery away from the motor when chosen
• Hanging pocket — suspends motor and battery together from an overhead support for users who prefer not to carry the motor
• Ergonomic backpack — symmetrical design with mesh fabric and reinforcement to move the motor away from the back; Cordura fabric is rain resistant and machine washable
• Belt — symmetrical Cordura and mesh belt; suspenders can be added to distribute weight to the shoulders. When belt is used, motor control buttons remain directly accessible

Water cooling

• To use water-cooled handpieces, either a water pump or the Equus Jet Connect is required. The water pump offers basic autonomous cooling; the Equus Jet Connect enables advanced care and remote control of handpiece cooling

Customization

• Product can be customised at order (option to engrave text on the motor and battery)

Technical specifications

• Reference: EL-ELC02
• Commercial name: Equus Liberty Connect
• Brand: Equus Dental Harmony
• Weight: 8.0 kg
• Max speed (depending on configuration): 10,000 rpm (no wireless pedal); 13,000 rpm (VM4 battery + wireless pedal); 17,000 rpm (V4A battery or transformer + wireless pedal)
• Power options: V4A battery (1 piece), VM4 battery (2 pieces), transformer (mains)
• Motor control: integrated control screen; digital DSP microprocessor
• Protections: electronic clutch for mouth protection; aluminium shock-resistant case for heat evacuation
• Functions: bidirectional rotation, stepwise speed variation, battery gauge display, start/stop, pump control (optional)
• Variants / accessories: multiple couplings available; supports: hanging ring, hanging pocket, belt, backpack; optional wireless controls: remote control, wireless single or double foot pedal
• Availability: Available
