Medical vacuum pump C-VLR 100/150

rotary clawoil-freedry

Overview
The C-VLR 100/150 series claw vacuum pumps provide dry, contact-free compression for industrial vacuum applications. Units deliver nominal capacities of approximately 100 and 150 m³/h with ultimate vacuums of 100 or 150 mbar (abs) in continuous operation. Standard configuration includes flange-mounted motor, integrated air-cooling fan, silencing hood, fine mesh intake filter, vacuum non-return valve and vacuum relief valve.

Standard features

• Dry, contact-free claw compression (no oil in the pumped medium)
• Flange-mounted motor
• Integrated fan for air cooling
• Silencing hood for reduced noise levels
• Fine mesh intake filter
• Vacuum non-return valve
• Vacuum relief valve

Benefits

• High efficiency owing to dry, contact-free compression for clean operation
• Consistent performance across operating range for reliable process results
• Integrated air cooling removes need for external cooling media
• Optional variable speed drive (VSD) to match performance to process demands
• Low maintenance design to reduce downtime
• Suitable for a wide range of industrial applications (packaging, plastics, woodworking, printing, medical, environmental, electronics, chemical, food processing)

Technical data (summary)

• Capacity range: 100 to 150 m³/h
• Ultimate vacuum: 100 mbar (abs) or 150 mbar (abs) depending on version
• Designed for continuous operation
• Cooling: integrated air-cooling fan
• Motor standard: flange-mounted motors compliant with DIN EN 60034
• Motor protection: IP55
• Motor insulation: Class F

Model / Technical specifications

• Model series: C-VLR 100/150
• Pumping principle: dry claw (contact-free) compression
• Nominal capacities: approx. 100 m³/h and 150 m³/h variants
• Ultimate vacuum (abs): 100 mbar or 150 mbar
• Cooling method: integrated air-cooled fan
• Standard accessories: silencing hood, fine mesh filter, vacuum non-return valve, vacuum relief valve
• Optional: variable speed drive (VSD) for process adaptation
• Motor: flange-mounted, DIN EN 60034 compliant, IP55, insulation class F
• Typical applications: packaging, plastics, woodworking, printing, medical, environmental, electronics, chemical, food processing
