Electric wheelchair DP-129

outdoorbeachfolding

Product overview
DP-129 folding beach electric wheelchair designed for outdoor and sandy-terrain mobility, featuring a steel frame and 40AH battery for moderate range.

Functions

• Steel frame
• Foamed rear wheel (diameter 32 cm)
• Equipped with safety lights
• PU armrest, turn-up type
• 40AH lead-acid battery
• Foam front wheel (diameter 20 cm)

Main parameters (unit cm)
Total length: 107 cm
Total width: 64 cm
Seat width: 46 cm
Rear wheel diameter: 32 cm
Front wheel diameter: 20 cm
Seat height: 58 cm
Total height: 107 cm
Backrest height: 48 cm
Range: 25 km
Speed: 1-7 km/h
Battery capacity: 40AH
Motor power: 200W x 2
Obstacle clearance: 4 cm
Climbing angle: 12°
Maximum load: 100 kg
Packing size: 110 x 64 x 75 cm
N.W.: 80.4 kg
G.W.: 98.2 kg

Additional information
DP-129 is offered by a professional electric wheelchair manufacturer in China. The product is designed to improve user comfort during outdoor use and the manufacturer provides selection assistance to choose the most suitable electric wheelchair for patient or user needs.

Technical specifications

• Model: DP-129
• Frame: Steel frame
• Rear wheel: Foamed rear wheel (diameter 32 cm)
• Front wheel: Foam front wheel (diameter 20 cm)
• Armrest: PU armrest, turn-up type
• Battery: 40AH lead-acid
• Motor: 200W x 2
• Speed range: 1-7 km/h
• Range: 25 km
• Climbing angle: 12°
• Maximum load: 100 kg
• Seat width: 46 cm
• Seat height: 58 cm
• Total dimensions (L x W x H): 107 x 64 x 107 cm
• Packing size: 110 x 64 x 75 cm
• Net weight: 80.4 kg
• Gross weight: 98.2 kg
