Digital video microscope OCM 162T251

for teachingfor biologyinspection

Overview

• Digital set combining the OCM 162 trinocular microscope and the ODC 251 tablet camera (C‑mount adapter included) for direct screen observation, documentation and measurement of samples.
• Product family: OCM‑S

OCM 162

• Ergonomic, stable design with a large working distance (72 mm), suitable for monitoring and analysis of cell cultures and other laboratory samples.
• 5 W LED transmitted illumination for bright‑field observation.
• Special Abbe condenser N.A. 0.3 with aperture diaphragm and fixed mounting; compatible with bright field, phase contrast and fluorescence applications.
• Mechanical stage with specimen holder (Ø 110 mm); brackets for petri dishes included or available as accessories.

ODC 251 (tablet camera included in set)

• Android tablet with 10.5" HD touch display and integrated 8 MP camera (1/1.8" sensor) for live view, image capture and 4K video recording.
• Live transfer from C‑mount camera to tablet, high‑resolution image and video capture for documentation and reporting.
• Measurement functions for distance and area; automatic white balance and automatic contrast adjustment for efficient workflows.
• Integrated interfaces: USB 2.0/3.0, Ethernet, Wi‑Fi, Bluetooth, HDMI output; data storage on USB stick and data transfer via USB cable supported.

Technical data
Optical system: Infinity
Tube type: Trinocular
Ocular magnifications: 10x
Ocular visual field: 22 mm
Standard objectives: 10×, 20×, 40×, PH 20×
Lens quality: Infinity Plan
Nosepiece screw‑in locations: 5
Illuminance: Transmitted light
Illumination intensity transmitted light: 5 W (LED)
Condensor type: Standard
Condenser - Aperture: 0.3
Condenser - Mounting: fixed
Working distance (condenser): 72 mm
Focusing mechanism: coaxial coarse and fine drive
Fine drive minimum: 0.002 mm
Display type: HD Touch Screen
Display screen size: 10.5"
MCU details: Rockchip RK3568 Quad‑Core
Camera - Sensor type: CMOS
Camera - Colour depth: Colour
Camera - Sensor size: 1/1.8"
Camera - Resolution: 8 MP 4K
Camera - Framerate: 30 fps
Interfaces: Ethernet, Bluetooth, WiFi, USB 2.0, USB 3.0, HDMI
Dimensions (W×D×H): 390×235×620 mm
GTIN/EAN number: 4045761490932

Applications & Use

• Monitoring and analysis of cell cultures and other laboratory samples.
• Suitable for laboratories, quality control, training and teaching where direct screen monitoring, documentation and measurement are required.

Included / Delivered

• Microscope (OCM 162)
• Tablet camera ODC 251 (Android tablet with integrated 8 MP 4K camera)
• C‑mount adapter
• Mechanical stage with specimen holder (Ø 110 mm)

Technical specifications

• Optical system: Infinity
• Tube type: Trinocular
• Oculars: 10× (field 22 mm)
• Objectives included: 10×, 20×, 40×, PH 20× (Infinity Plan)
• Nosepiece: 5 positions
• Illumination: Transmitted LED 5 W
• Condenser: Abbe N.A. 0.3, fixed, W.D. 72 mm
• Focusing: Coaxial coarse and fine drive; fine drive 0.002 mm
• Stage: Mechanical with Ø 110 mm specimen holder
• Camera/tablet: CMOS 8 MP (1/1.8"), 4K, 30 fps; HD touch display 10.5"
• Interfaces: Ethernet, Bluetooth, Wi‑Fi, USB 2.0/3.0, HDMI
• Dimensions: 390×235×620 mm
• GTIN/EAN: 4045761490932
