Manual deblistering machine S50

pneumaticcompactblister

Overview
The S50 is a compact, fully pneumatic de-blistering machine designed for the recovery of products from PVC-ALU and ALU-ALU blister packs. It is format-based and intended for small batch processing.

Operation
The operator selects the required format, loads parts into the mould, and uses two-hand safety pushbuttons to rotate the table into position under the workstation to start the cycle. At cycle end the operator repeats the table rotation to remove the empty blister and load the next one. Format-based and dedicated moulds can be supplied on request, with custom configurations and external dimensions.

Main characteristics

• Pneumatic manual de-blistering machine
• One blister per stroke, max dimensions 90 × 70 mm
• Format-based / dedicated moulds available on request
• Pressure applied via manual mechanical system
• Possibility to customize moulds and configurations
• Product recovery bin for manual collection

Production

• Production rate: 6 bpm (blisters per minute)

Technical specifications
Machine layout (WxDxH): 350 mm x 400 mm x 670 mm
Weight: 15 kg
Consumptions: not available

Model and detailed specifications

• Model: S50
• Machine type: Pneumatic manual de-blistering machine
• Blisters per stroke: 1
• Maximum blister dimensions per stroke: 90 × 70 mm
• Production speed: 6 bpm (blisters per minute)
• Formats: Dedicated / format-based moulds available on request
• Pressure system: Manual mechanical system
• Customization: Possibility to customize moulds and configurations
• Product handling: Product recovery bin
• Machine layout (WxDxH): 350 mm x 400 mm x 670 mm
• Weight: 15 kg
• Consumptions: not available
