Dual-core medical panel PC Venus-153

Intel® Celeron®Intel® Core i5for healthcare facilities

Product overview
15.6" medical panel PC offering Intel processor options (Celeron to Skylake Dual‑Core i5), dual hot‑swappable batteries for continuous 24/7 operation, designed for clinical environments with medical‑grade safety and easy cleaning.

Key features

• Highest level of medical safety protection: EMC 4.1 / Safety 3.2
• Cleanable with hospital solvents and disinfectants
• Hot‑swappable dual‑battery design supporting 24/7 runtime
• Intel Skylake Dual‑Core i5 option available
• Remote monitor/control/update support (ORION compatible)
• Isolated LAN and COM ports for medical connectivity
• Front protection IP65, rear IPX1

Specifications
System

• Processor: Intel Celeron; Intel Skylake (Dual‑Core i5 option)
• System memory: 16 GB
• Storage: M.2 SSD up to 512 GB
• OS support: Windows 7, Windows 10, Ubuntu 18.04 LTS, IGEL
• Security: Trusted Platform Module (TPM) 2.0
• Wireless: Bluetooth 4.0 (optional); 802.11ac/a/b/g/n

Display

• Size: 15.6" FHD (1920 x 1080)
• Brightness: 220 nits; Contrast ratio: 500:1; Colors: 262K

I/O

• USB: USB 2.0; USB 3.0 Type‑A
• Video out: HDMI x1
• Serial port: COM x1
• Ethernet: Gigabit LAN x2 (isolated)

Mechanical and Environmental

• Power: DC‑in; dual battery support; hot‑swappable
• Protection: IP65 front, IPX1 rear
• Operating temperature: 0°C ~ 35°C; Storage temperature: -20°C ~ 60°C
• Storage humidity: 10% ~ 95% @ 40°C, non‑condensing
• Dimensions (WxDxH): 392 x 43 x 265 mm; Net weight: 2.7 kg; Gross weight: 4.7 kg
• Certifications: CE (ITE & Medical), FCC (Medical & ITE), UL, cUL, TELEC

Technical specifications

• Model: Venus-153
• Brand: Onyx Healthcare Inc.
• Audio: 3W x 2 speakers
