CAD/CAM milling machine AnyCam 42W
dentalfor zirconiafor dental plaster

CAD/CAM milling machine
CAD/CAM milling machine
Add to favorites
Compare this product


Characteristics

Type
CAD/CAM
Applications
dental
Designed for
for zirconia, for dental composites, for titanium, for metal, for PMMA, for dental plaster
Machining type
wet machining
Spindle speed

Min.: 15,000 rpm
(94,248 rad.min-1)

Max.: 60,000 rpm
(376,991 rad.min-1)

Power

190 W

Height

600 mm
(23.62 in)

Depth

560 mm
(22.05 in)

Weight

61 kg
(134.48 lb)

Description

The DWX-42W – is one of the most accurate standalone wet milling devices ever built. A smooth and steady ball-screw driven system provides exceptionally precise, esthetically accurate results for glass ceramic, composite resin, PMMA, and titanium applications. A fourth axis allows the DWX-42W to rotate and tilt pin-type material for deep undercuts, simultaneously producing multiple dental restorations with ease. Paired with the AK-1 Abutment Milling System, the DWX-42W offers a complete solution for milling custom abutments from titanium blanks produced by popular manufacturers like DESS, NT-Trading, MEDETiKA®, and GeoMedi. Custom titanium abutments are easy to produce in-house using the DWX-42W and AK-1 Abutment Milling System. Switch in minutes to production of custom abutments, avoiding the hassles of outsourcing and making the production process faster, more convenient and more cost effective than ever. TECHNICAL FEATURES Pin type (Width × depth × height): max. 40 × 20 × 20 mm (1.5 × 0.8 × 0.8 in.) Operating speed XYZ: 6 to 1800 mm/min (0.24 to 70.9 in./min.) Rotary axis travel angle: A: ±360° Number of milling burs housed: 6 Attachable milling bur: Shank diameter: 3 mm, dedicated milling bur Compatible compressed air: 0.18 to 0.22 MPa Interface USB, Ethernet (10 BASE-T/100 BASE-TX automatic switching) Control command sets: RML-1, NC code Power requirements: AC 100 to 240 V ± 10%, 50/60 Hz (overvoltage category: II, IEC 60664- 1), 2.1A Operating noise During operation: 70 db (A) or less (when not cutting)
