Animal research isolator LH6-1D series

for biocontainmentfloor-standingwith HEPA filter

Product Introduction
Provides an integrated isolation solution for the production and maintenance of germ-free miniature pigs, combining hysterectomy units, sterile transfer systems and germ-free rearing isolators. The workflow minimizes exposure risk to preserve sterility, enabling efficient procedures and a secure sterile environment.

Features

• Hysterectomy unit with trough transfer channel and double-sided flat-sealed doors to facilitate transfer and eliminate sterilization dead zones.
• Sterile transfer trolley docks via sterile transfer port to ensure animals and materials remain protected from external contamination during transfer.
• Dedicated waste removal design prevents cross-contamination between internal and external environments.
• Inlet and exhaust fitted with H14 HEPA filters (99.995% MPPS efficiency per EN1822).
• Ergonomic tilted front face for operator access with viewing windows, glove ports and active inflatable sealing to maintain stable sterile conditions.
• Chamber interior is a rigid integrated welded structure with smooth surfaces and rounded corners; free of burrs, sharp edges or cleaning dead zones. Leakage rate < 0.5% Vol/hr at 2× working pressure.
• Reserved VH2O2 interfaces for external vaporized hydrogen peroxide generators or optional integrated VH2O2 systems.
• Environmental monitoring: pressure differential, temperature, humidity and ammonia concentration measurement supported.
• Built-in lighting for convenient operation and routine tasks.

Specifications
Model: LH6-1D-G4 | Model: LH6-1D-G8
Function: Hysterectomy | Function: Germ-free rearing
Overall Dimensions: L1700×W800×H1950 mm | Overall Dimensions: L1700×W1220×H2150 mm
Chamber Dimensions: L1200×W800×H700 mm | Chamber Dimensions: L1600×W1200×H920 mm
Operation Method: Double-sided operation, equipped with 2 sets of integrated sleeves on each operating face | Operation Method: Double-sided operation, equipped with 4 sets of integrated sleeves on each operating face
Transfer Channel: Sterile transfer port, docks with sterile transfer trolley via dunk tank; mechanical sealing for chamber interior and exterior | Transfer Channel: Sterile transfer port, docks with sterile transfer trolley for waste transfer channel; isolates and transfers out waste
Sealed Door: Tempered glass viewing window, active inflatable sealing | Sealed Door: Tempered glass viewing window, active inflatable sealing
Pressure Control: Adjustable from (-150) to 150 Pa; differential pressure between interior and exterior ≥ 50 Pa | Pressure Control: Adjustable from (-150) to 150 Pa; differential pressure between interior and exterior ≥ 50 Pa
Airflow Control: Air changes ≥ 20 times/h | Airflow Control: Air changes ≥ 20 times/h
Caging: / | Caging: Built-in pig cage

Applications

• Support production and maintenance of germ-free miniature pigs for biomedical and translational research.
• Hysterectomy operations and sterile transfer procedures for derivation of germ-free animals.
• Germ-free rearing isolators for large-animal research, sterile husbandry and facility integration.

Technical specifications

• Models: LH6-1D-G4 and LH6-1D-G8 (LH6-1D series).
• Functions: hysterectomy (LH6-1D-G4) and germ-free rearing (LH6-1D-G8).
• Dimensions: overall and chamber dimensions specified per model (see Specifications block).
• Operation: double-sided operation with integrated sleeves (2 sets for G4, 4 sets for G8).
• Transfer channel: sterile transfer port docking with sterile transfer trolley; mechanical sealing / dunk tank docking.
• Filtration: inlet and exhaust with H14 HEPA filters (99.995% MPPS per EN1822).
• Sealed doors: tempered glass viewing windows with active inflatable sealing and glove access on operating face.
• Environmental control: adjustable pressure (-150 to 150 Pa) with ≥50 Pa differential, airflow ≥20 air changes/hour.
• Leakage performance: < 0.5% Vol/hr at 2× working pressure.
• VH2O2 support: reserved interfaces for external VH2O2 generators or optional built-in VH2O2 systems.
• Monitoring: pressure differential, temperature, humidity and ammonia concentration measurement supported.
• Caging: built-in pig cage option available for LH6-1D-G8.
