Chemical fume hood VALUELINE

exhaustlaboratoryfor research laboratories

Product overview
TopAir Valueline ductless fume hoods are benchtop units designed to protect laboratory personnel from common chemical fumes. The cost-effective range features an intelligent control system with a 7″ color touchscreen, airflow monitoring and alarms, integral sealed polypropylene worktop, sliding front sash with counterweight, energy-efficient EC fan and LED lighting. Multiple HEPA/ULPA and specific carbon filters are available to adapt protection to the application. Units can be supplied in several widths and customized on request.

Structure

• 8 mm welded polypropylene chamber with high chemical resistance
• Built-in sealed polypropylene worktop
• 5 mm tempered safety front glass with sliding sash and counterweight
• Tempered glass side windows for improved visibility

Features

• 7″ color touchscreen microprocessor control with airflow display
• Airflow alarm and service/filter replacement alerts
• 10-level EC fan speed control for energy-efficient operation
• Chamber alert light (red) for critical alarms
• 800 lux eco-friendly LED illumination
• Air velocity target: 0.5 ± 0.1 m/s (100 ± 20 fpm)
• Back access for easy filter replacement
• Variety of HEPA, ULPA and specialty carbon filters (acids, bases, solvents, formaldehyde, multi-gas)
• 10″ (250 mm) exhaust collar for optional external exhaust connection
• Optional metal stand with casters or polypropylene base cabinet
• Certification: CE

Models (spec / model table)
Spec / Model — VL-CF-090-PP — VL-CF-120-PP — VL-CF-150-PP — VL-CF-180-PP
Outer Dimensions (W x D x H) — 900 x 630 x 1050 mm / 35.4 x 24.8 x 41.3″ — 1200 x 630 x 1050 mm / 47.2 x 24.8 x 41.3″ — 1500 x 630 x 1050 mm / 59.1 x 24.8 x 41.3″ — 1800 x 630 x 1050 mm / 70.86 x 24.8 x 41.3″
Workspace (W x D x H) — 880 x 450 x 550 mm / 34.6 x 17.7 x 21.6″ — 1180 x 450 x 550 mm / 46.4 x 17.7 x 21.6″ — 1480 x 450 x 550 mm / 58.3 x 17.7 x 21.6″ — 1780 x 450 x 550 mm / 70 x 17.7 x 21.6″
Max sash working height — 500 mm / 19.7″ (all models)
Microprocessor control — 7″ touchscreen with airflow alarm, 10-speed fan control, filter replacement alarm, service alarm, lights control
Air velocity — 0.5 ± 0.1 m/s (100 ± 20 fpm)
Hood material — Welded white polypropylene structure with built-in sealed polypropylene worktop
Noise level (measured 20 cm from worktable, 1.2 m above ground) — <55 dB (VL-CF-090-PP), <57 dB (VL-CF-120-PP), <60 dB (VL-CF-150-PP), <60 dB (VL-CF-180-PP)
Power supply — 110/220 V, 50/60 Hz, single phase
Illumination — 800 lux eco-friendly LED lighting
Metal stand with casters (models) — VL-CF-090-ST, VL-CF-120-ST, VL-CF-150-ST, VL-CF-180-ST

Accessories

• CF-CB — clear back (for educational/demonstration purposes)
• CF-xxx-AC — acid carbon filter
• CF-xxx-BS — base carbon filter
• CF-xxx-CR — carbon filter for solvents
• CF-xxx-FMD — formaldehyde carbon filter
• CF-xxx-HP — HEPA filter
• CF-xxx-MG — multi-gas carbon filter
• CF-xxx-UL — ULPA filter
• CF-GTAP — gas tap
• CF-WTAP — water tap

Technical specifications

• Benchtop ductless fume hood for protection against chemical fumes
• 7″ color touchscreen control with airflow monitoring and alarms
• 10-level EC fan speed control
• Air velocity target: 0.5 ± 0.1 m/s (100 ± 20 fpm)
• Built-in sealed polypropylene worktop (high chemical resistance)
• Welded polypropylene chamber (8 mm)
• Tempered safety front glass (5 mm) with sliding sash and counterweight
• Tempered glass side windows for visibility
• 800 lux LED lighting (eco-friendly)
• Back access for filter replacement
• Filter options: HEPA, ULPA and multiple carbon filter types
• 10″ (250 mm) exhaust collar for external exhaust connection
• Noise level: approx. <55–60 dB depending on model
• Power: 110/220 V, 50/60 Hz, single phase
• Optional metal stand with casters or polypropylene base cabinet
• Brand: TopAir — Series: Valueline
• Certification: CE
