Chemical fume hood CF-120-HCV

exhaustcontainmentlaboratory

Product overview
TopAir ductless hybrid laminar airflow hoods combine the containment function of ductless fume hoods with a laminar clean bench down-flow. They are designed for laboratories requiring Class 100 / ISO 5 conditions at the work area while providing operator protection via a front inflow.

Filtration and airflow

• Dual filtration: independent supply and exhaust paths
• Supply path: pre-filter, HEPA and fan producing a laminar down-flow over the workspace
• Exhaust path: activated carbon filter and fan that collect down-flow and create protective inflow at the front sash
• Both inflow and down-flow pass through the carbon filter before being exhausted back to the laboratory

Structure

• 8 mm welded white polypropylene with high chemical resistance
• Double back wall with baffle for airflow control
• Built-in sealed polypropylene worktop (stainless steel optional)
• Tempered glass full-opening sliding front sash with counterweight
• Extraction collar for optional external exhaust

Features

• 10.1” color touchscreen display
• VAV control with airflow alarm and real-time display
• Automatic laminar down-flow velocity with manual inflow adjustment; safety shutdown of down-flow if inflow fails
• VOC sensor with alarm and chamber alert light (red)
• Cleanliness level: Class 100 / ISO 5
• 800 lux LED lighting isolated from the work area
• Includes polypropylene lower base cabinet
• CE certified

Models (table)
Spec / Model | CF-120-HCV | CF-150-HCV | CF-180-HCV | CF-200-HCV | CF-250-HCV
Outer Dimensions for standard model W x D x H | 1200 x 950 x 2420 mm — 47.3 x 37.4 x 95.2” | 1500 x 950 x 2420 mm — 59.0 x 37.4 x 95.2” | 1800 x 950 x 2420 mm — 70.9 x 37.4 x 95.2” | 2000 x 950 x 2420 mm — 78.7 x 37.4 x 95.2” | 2500 x 950 x 2420 mm — 98.4 x 37.4 x 95.2”
Workspace (W x D x H) | 1000 x 600 x 700 mm — 39.4 x 23.6 x 27.5” | 1300 x 600 x 700 mm — 51.2 x 23.6 x 27.5” | 1600 x 600 x 700 mm — 63 x 23.6 x 27.5” | 1800 x 600 x 700 mm — 70.8 x 23.6 x 27.5” | 2300 x 600 x 700 mm — 90.5 x 23.6 x 27.5”
Front Sash Max. Opening / Sash Working Height | 600 mm / 23.6” — 300 mm / 12” (applies to models listed)
Inflow | 0.5 ± 0.1 m/s — 100 ± 20 fpm
Down flow | 0.33 ± 0.1 m/s — 66 ± 10 fpm
Hood Material | 8 mm welded white polypropylene structure with built-in sealed polypropylene worktop
Cleanliness Level | Class 100 / ISO 5
Work Table | Polypropylene / Stainless steel
Control System | VAV System with 10.1” color touch screen
Optional | Water tap / gas tap / vacuum tap / polypropylene sink
Power Supply | 110 / 220 V, 50/60 Hz, single phase

Accessories (table)
Model | Description
CF-GTAP | Gas tap
CF-PP-SINK | Polypropylene cup sink
CF-WTAP | Water tap
FH-GTAP | Gas tap
FH-SOCKET | Power outlet

Technical specifications

• Dual filtration: HEPA + activated carbon (supply and exhaust paths)
• HEPA supply creates laminar down-flow; exhaust carbon filter creates protective front inflow
• Inflow velocity: 0.5 ± 0.1 m/s (100 ± 20 fpm)
• Down-flow velocity: 0.33 ± 0.1 m/s (66 ± 10 fpm)
• Cleanliness: Class 100 / ISO 5
• Construction: 8 mm welded polypropylene; double back wall with baffle
• Worktop options: sealed polypropylene (standard) or stainless steel (optional)
• Control: VAV system with 10.1” color touchscreen; airflow alarm and display
• Sensors/alarms: VOC sensor and alarm; chamber alert light (red)
• Lighting: 800 lux LED (independent from work area)
• Front sash: tempered glass, full-opening sliding with counterweight; max opening 600 mm, working height 300 mm
• Power: 110/220 V, 50/60 Hz, single phase
• Available accessories: water/gas/vacuum taps, polypropylene sink, power outlet
• Certifications: CE certified
