Thermal transfer printer ZT200 Series

direct thermallabelbarcode label

Overview
The ZT200 Series is a compact industrial label printer family designed for straightforward setup, reliable thermal transfer and direct thermal printing, and optional UHF RFID print‑and‑encode capability. It targets warehouse, logistics, light manufacturing and retail back‑office label applications where space, usability and manageability are priorities.

Models in this series

• ZT231 — 4‑inch industrial label printer, thermal transfer / direct thermal; large color touchscreen and common platform components.
• ZT231 RFID — 4‑inch industrial printer with integrated UHF RFID print‑and‑encode capability for tagging, compliance and inventory visibility.

Key benefits

• Serviceability: tool‑less platen and printhead removal and side‑loading media path reduce maintenance time.
• Space‑efficient design: compact chassis with bi‑fold door requiring minimal swing for installations in confined workspaces.
• Cost‑effective versatility: shared platform across models supports multiple media types and optional RFID for expanded use cases.

Software & management features

• Zebra DNA for Printers — tools for setup, security, remote management and lifecycle optimization.
• Printer Setup Utilities — simplify initial configuration and improve deployment consistency.
• PrintSecure — features to protect connections and prevent unauthorized access.
• Printer Profile Manager Enterprise — browser‑based discovery and distribution of printer configurations.

Supplies & accessories (high level)

• RFID labels and tags for UHF RFID printing and encoding.
• Barcode labels and tags (paper and synthetic) for thermal transfer or direct thermal printing.
• Thermal transfer ribbons (wax, wax/resin, resin) compatible with the ZT200 Series.
• Genuine Zebra printhead kits, wireless card kits, RFID upgrade modules and other service/accessory items.

Resources & warranty (summary)

• Specification sheets, technical manuals and product brochures available per model (ZT231, ZT231 RFID).
• Downloads: setup guides, printhead and options guides, application briefs and ROI tools.
• Warranty: subject to Zebra hardware warranty terms — minimum 1 year from shipment (regional variations possible).

Technical specifications (high level)

• Print width: 4 in (≈102 mm).
• Print technology: Thermal Transfer and Direct Thermal.
• Print speed: up to 8 ips (203 mm/s) and up to 12 ips (305 mm/s) depending on configuration.
• Print resolution: 203 dpi and 300 dpi options.
• Connectivity: USB, Ethernet; optional Wi‑Fi 5 (802.11ac) and Bluetooth Low Energy.
• Available variants: standard 4‑inch industrial (ZT231) and RFID‑enabled 4‑inch (ZT231 RFID, print & encode).
• Serviceability: tool‑less platen and printhead removal; side‑loading media path.
• Warranty: minimum 1 year (regional variations possible).
