Laboratory fume hood P-11

floor-standinglaminar flowstainless steel

Intended use
Small tabletop clean hood designed for localized purification around microscopes and temporary storage of samples. The stainless pipe frame minimizes footprint to preserve bench space.

Key features

• Simple assembly for tabletop installation.
• Purification capability in limited bench space.
• Vinyl hood interior achieves ISO 6 (Class 1000) cleanliness.

Models and specifications
Pipe hood P-11
Model: P-11
Cleanliness: ISO6 (Class 1000)
Airflow: Approx. 1 m³/min
External dimensions: W500 mm × D500 mm × H700 mm

Pipe hood P-21
Model: P-21
Cleanliness: ISO6 (Class 1000)
Airflow: Approx. 2 m³/min
External dimensions: W1000 mm × D500 mm × H700 mm

Technical characteristics

• Models: P-11, P-21
• Cleanliness class: ISO6 (Class 1000)
• Airflow: ≈1 m³/min (P-11), ≈2 m³/min (P-21)
• Dimensions: P-11 = W500×D500×H700 mm, P-21 = W1000×D500×H700 mm
• Frame material: stainless steel pipe
• Applications: localized purification around microscopes, temporary sample storage in confined bench spaces
• Installation: tabletop, easy assembly
