HEPA filter CleanSeal Side-C

airfor clean roomsfor healthcare facilities

Overview
Fully welded terminal HEPA filter housing for ceiling installation, with side circular duct connection and optional adjustment damper, adjustable from the room. Suitable for supply or exhaust airflow, compliant with standards in Cleanrooms or other controlled environments. Open to customization.

Key features

• Optional with damper, adjustable from the room
• Toolless filter clamping 100% secured and immediate
• Built-in filter scaling option
• Quick front plate locking for immediate access to the filter
• Complete interchangeable diffusion front plates range
• Robust fully welded construction for durable reliability and tightness
• High corrosion protection against decontamination agents

Available variants / Sizes (Model | Width (mm) | Height (mm) | Depth (mm) | Filter size Width (mm) | Filter size Height (mm))
CL-SW-3P3-P-xx-S-C-160-N-00-AAA0 | 367 | 355 | 410 | 305 | 305
CL-SW-3P6-P-xx-S-C-200-N-xx-AAA0 * | 660 | 367 | 450 | 610 | 305
CL-SW-4P4-P-xx-S-C-200-N-00-AAA0 | 519 | 507 | 450 | 457 | 457
CL-SW-4P4-P-xx-S-C-250-N-00-AAA0 | 519 | 507 | 500 | 457 | 457
CL-SW-5P5-P-xx-S-C-250-N-00-AAA0 | 570 | 558 | 500 | 508 | 508
CL-SW-5P5-P-xx-S-C-315-N-00-AAA0 | 570 | 558 | 565 | 508 | 508
CL-SW-6P6-P-xx-S-C-250-N-00-AAA0 | 672 | 660 | 500 | 610 | 610
CL-SW-6P6-P-xx-S-C-315-N-00-AAA0 | 672 | 660 | 565 | 610 | 610
CL-SW-9P6-P-xx-S-C-315-N-xx-AAA0 * | 965 | 672 | 565 | 915 | 610
CL-SW-9P6-P-xx-S-C-355-N-xx-AAA0 * | 965 | 672 | 605 | 915 | 610
CL-SW-9P9-P-xx-S-C-315-N-00-AAA0 | 977 | 965 | 565 | 915 | 915
CL-SW-9P9-P-xx-S-C-355-N-00-AAA0 | 977 | 965 | 605 | 915 | 915
CL-SW-11P5-P-xx-S-C-315-N-xx-AAA0 * | 1158 | 570 | 565 | 1108 | 508
CL-SW-11P5-P-xx-S-C-355-N-xx-AAA0 * | 1158 | 570 | 605 | 1108 | 508
CL-SW-12P6-P-xx-S-C-315-N-xx-AAA0 * | 1270 | 672 | 565 | 1220 | 610
CL-SW-12P6-P-xx-S-C-355-N-xx-AAA0 * | 1270 | 672 | 605 | 1220 | 610

Specifications

• Application: Turbulent airflow in clean rooms and other controlled environments, for ceiling installation.
• Installation options: Universal mounting system for both suspended installation and compression mounting.
• Construction / Comments: Construction: Steel, fully welded. Finish: Decontamination resistant double-layer powder coat. Standard color RAL 9010 (SW) or custom RAL. Option: Stainless steel SS 304 (S4) or SS 316L (S6). Filter Gaskets: PU or GEL. Filters PU: MEGALAM MD(66mm)/(78mm)/MX(90mm)/MG(110mm). Filters GEL: MEGALAM MD(71mm)/MX(105mm)/MG(115mm). Control equipment: Room side accessible upstream pressure port and concentration port, plus +/- secondary ports for remote pressure drop reading. Option: Damper, adjustable from the room.

Caractéristiques / spécifications techniques

• Fully welded steel construction for tightness and durability
• Decontamination resistant double-layer powder coat finish
• Optional stainless steel versions: SS 304 (S4) or SS 316L (S6)
• Filter gasket options: PU or GEL
• Compatible filter types and depths: MEGALAM PU and GEL variants (see specifications for exact depths)
• Room-side accessible ports for upstream pressure and concentration measurement
• Optional room-adjustable damper for airflow control
• Toolless filter clamping and quick front plate locking for immediate access
