Hospital trolley B37

transfertransporttransfer

Product name
Liquid Basket Transfer Trolley B37 for PIVAS

Core Advantages

• Designed specifically for PIVAS (pharmacy intravenous admixture rooms) workflows.
• Integrated welded 304 stainless steel structure with a seamless design to eliminate sanitary dead corners for frequent disinfection.
• Two high-load tiers with three-sided stainless steel guardrails per layer to prevent items from falling.
• Equipped with Φ100mm medical silent casters featuring dual brake and dual directional functions; factory 5-year caster warranty.
• Factory pre-assembled and fully customizable for dimensions, tier spacing, guardrails and accessories to suit clinical workflows.

Key Specifications

• Material: National standard 304 stainless steel.
• Frame tube: Φ25mm thickened stainless steel round tube, wall thickness ≥ 1.0mm.
• Shelves: 0.8mm thick stainless steel plates; rated load ≥ 50 kg per tier; 2 tiers.
• Guardrails: Φ12.7mm stainless steel rails on three sides of each layer.
• Casters: Φ100mm medical silent casters, dual brake & dual directional, ≥50 kg single-wheel load; 5-year warranty.
• Craft: Full welding with fine overall polishing.
• Assembly: Pre-assembled at factory, ready to use.
• Customization: Full customization available (overall size, layer spacing, number of tiers, guardrails, accessories).
• Certification: 304 stainless steel material test reports available.

Dimensions

• Overall: 600×400×930 mm.
• Top shelf height from ground: 850 mm.

Application Scenarios
Intended for pharmacy intravenous admixture rooms (PIVAS) for liquid preparation, sorting and basket transport. Also suitable for outpatient dispensing rooms, operating rooms, treatment rooms, laboratories, pharmacies, community clinics and medical aesthetic centers. Used for classified storage and transport of finished infusions, medicines, dressings, consumables and laboratory samples.

Selling Points

• One-piece welded stainless steel structure without sanitary dead corners.
• Double high-load tiers with three-sided guardrails for secure storage.
• Corrosion-resistant 304 stainless steel with polished surfaces for easy disinfection.
• Φ100mm silent dual-brake casters for smooth and stable movement in confined spaces.
• Fully customizable to match different clinical layouts and workflows.

Technical specifications

• Model: B37.
• Material: 304 stainless steel (national standard).
• Frame tube: Φ25mm, wall thickness ≥ 1.0mm.
• Shelf thickness: 0.8mm stainless steel; load capacity ≥ 50 kg per tier; 2 tiers.
• Guardrails: Φ12.7mm stainless steel on three sides per layer.
• Casters: Φ100mm medical silent casters, dual brake & dual directional; ≥50 kg single-wheel load; 5-year warranty.
• Finish: Full welding and fine overall polishing.
• Assembly: Pre-assembled at factory.
• Customization: Overall size, layer spacing, number of tiers, guardrails and accessories available.
• Dimensions: 600×400×930 mm (overall); top shelf height 850 mm.
• Certification: 304 stainless steel material test reports available.
