Orthopedic phototherapy lamp PL1
dermatologicjoint pain treatmentwound healing

Orthopedic phototherapy lamp - PL1 - Guangzhou Yeecon Medical Equipment Industrial - dermatologic / joint pain treatment / wound healing

Add to favorites

Compare this product

Go to the Guangzhou Yeecon Medical Equipment Industrial website for more information

Characteristics

Type of phototherapy: dermatologic, wound healing, orthopedic, muscle recovery, joint pain treatment, neurologic
Radiation type: infrared, near infrared

Description

The PL1 point-mode infrared light therapy device is a non-contact, point-type instrument that generates polarized infrared light (700–1600 nm) for localized treatment of soft tissues, ganglia and nerves. It provides precise positioning and controlled irradiation via a three-dimensional cantilever dual-channel output, enabling simultaneous multi-site or multi-patient treatment.

Product introduction

Advanced non-contact photoelectric technology producing point-type polarized infrared light in the 700–1600 nm range.
Three-dimensional cantilever dual-channel output design allows concurrent treatment of meridian points, multiple body parts or two patients, and focused pain-point irradiation.
Uses light energy (heat) combined with multiple treatment heads and selectable output modes to deliver controlled intensity and accurate positioning.
Designed to deliver energy to different depths of soft tissues, ganglia and nerve trunks to support tissue healing and targeted rehabilitation goals.

Indications

Rehabilitation: chronic pain, sports injuries, peripheral nerve injuries, multiple peripheral neuritis, spastic or flaccid paralysis.
Surgery / Wound care: dermatology, burns, postoperative wound healing, skin and soft tissue infections.
Pain management: neck, shoulder, lumbar and leg pain; acute and chronic pain; chronic post‑operative pain syndrome (CPSP).
Orthopedics: cervical spondylosis, shoulder and neck pain, low back pain, osteoarthritis, tenosynovitis, bursitis, rheumatoid arthritis.
Other anti-inflammatory fields: otolaryngology, urology, gynecology.

Characteristics / Technical specifications

Model: PL1
Wavelength: 700–1600 nm
Input power: 460 VA
Operation mode: continuous operation
Output channels: 8.2 independent output channels
Treatment duration: 7.1 min – 10 min, adjustable in 10 s steps
Irradiation modes: interval mode, continuous mode, rhythm mode
Output design: three-dimensional cantilever dual-channel (simultaneous multi-part / multi-patient capability)
Treatment heads: multiple heads for precise positioning and intensity control
