Optical microscope Ceti Max III

compoundfor teachinglaboratory

erfect for teaching laboratories, the Ceti Max III Monocular Compound Microscope with 4x, 10x, 40x & 100x Achromatic Objectives features an achromatic optical system, which produces clear and sharp images. The wide-field 10x eyepiece produces a substantial field-of-view that allows users to observe samples of different sizes. The quadruple reversed nosepiece allows this microscope to be handled comfortably while adjusting magnification levels. A range of high clarity objectives are supplied as standard. Wide-field 10x eyepiece produces a substantial field-of-view that allows users to observe samples of different sizes. The quadruple reversed nosepiece allows this microscope to be handled comfortably while adjusting magnification levels. A range of high clarity objectives are supplied as standard. Eyepiece: 10x / 18mm widefield with pointer Nosepiece: Quadruple reversed, revolving with click stop Objectives: 4x, 10x, 40x and 100x (oil) Achromatic Condenser: Brightfield Abbe – N.A. 1.25, precentred, focusable with iris diaphragm and filter holder Stage: 160 x 140mm with built-in mechanical stage and slide holder, 75 x 50mm movement, Vernier scale Focusing Knobs: Coaxial coarse and fine with stop Illumination: 20W Halogen Mains Power: 100 – 240V, 50 / 60Hz Supplied With: Immersion oil (5ml), blue filter, dust cover, power cord with unique ‘self-store’ system and instruction manual
