Healthcare facility medical computer ACCEL-JS1500

AI-assistedwith USBHDMI

Overview
The ACCEL-JS1500 is a medical AI imaging workstation based on the NVIDIA Jetson T5000 (Blackwell) platform, designed for edge deployment in clinical imaging workflows and diagnostic systems. It supports JetPack 7.0, hardware security with TPM 2.0 and multiple certified interfaces for medical and ITE environments.

Key features

• AI performance: up to 2070 TFLOPS (FP4)
• 14-core Arm Neoverse-V3AE 64-bit CPU
• 128 GB LPDDR5X (256-bit), up to 273 GB/s bandwidth
• High-speed networking: 1 × QSFP28 (4 × 25GbE) and 1 × 5GbE
• Extensive I/O: 4 × USB 3.2 Gen 2 (Type-C/Type-A), additional USB 2.0, dual video outputs
• Storage: 2 × M.2 M-key NVMe slots

System
Model: ACCEL-JS1500
AI Platform: NVIDIA Jetson T5000 (Blackwell)
Processor: 14-core ARM Neoverse-V3AE 64-bit
OS Support: JetPack 7.0
System Memory: 128 GB LPDDR5X
Security: Trusted Platform Module 2.0 (TPM 2.0)
Storage: 2 × M.2 M Key NVMe
Speaker: 2W × 2
Function Key: 5 × configurable membrane keypad

Display
Display Size: 7-inch

I/O
Network: QSFP28 (4 × 25GbE), 1 × 5GbE
USB: USB 2.0; USB 3.2 Gen 2 (Type-C and Type-A) – total 4 ports
Video Out: HDMI ×1, DisplayPort 1.4 ×1 (dual video output support)
Audio: Line-out, Mic-in; Speakers: 2W ×2

Mechanical and Environmental
Power Supply: DC-in
Operating Temperature: 0°C to 35°C (32°F to 95°F)
Storage Temperature: -20°C to 60°C (-4°F to 140°F)
Dimensions (WxDxH): 322 × 225 × 149 mm
Certifications: CE (ITE), CE (Medical), FCC (Medical), FCC (ITE), UL, cUL

Technical specifications

• Model: ACCEL-JS1500
• AI Platform: NVIDIA Jetson T5000 (Blackwell)
• CPU: 14-core ARM Neoverse-V3AE 64-bit
• GPU Performance: up to 2070 TFLOPS (FP4)
• Memory: 128 GB LPDDR5X (256-bit), up to 273 GB/s
• Storage: 2 × M.2 M Key NVMe
• Network: 1 × QSFP28 (4 × 25GbE), 1 × 5GbE
• USB: 4 × USB 3.2 Gen 2 (incl. Type-C/Type-A), plus USB 2.0
• Video Outputs: HDMI ×1, DisplayPort 1.4 ×1 (dual video output support)
• Audio: Line-out, Mic-in; Speakers: 2W ×2
• OS Support: JetPack 7.0
• Security: TPM 2.0
• Environmental: Operating 0°C–35°C; Storage -20°C–60°C
• Dimensions: 322 × 225 × 149 mm
• Certifications: CE (ITE), CE (Medical), FCC (Medical), FCC (ITE), UL, cUL
