Anatomy simulator CVC-B01

for general carepalpationpuncture

Overview
This modular training platform supports central venous catheterization and port access training with cost-effective, replaceable consumables. It provides dual pulsatility simulation via a hand pump (or optional Electro-hydraulic Pulse Generator), and a durable self-healing neck muscle pad designed for repeated practice. The system is portable and configurable for multiple procedures.

Procedures

• Ultrasound-guided CVC line implantation
• External landmark catheterization for CVC lines
• Insertion techniques for PermCath, Hickman catheters and CVP-Cath
• Port access, puncture and care

Features

• Neck muscle pad incorporates a clavicle skeleton design enabling palpation of insertion landmarks and improved ultrasound-guided accuracy
• Ultrasound-compatible materials enhance visibility of vascular anatomy under ultrasound
• Self-healing neck muscle pad supports up to 50 punctures
• Hand pump allows adjustable aortic pressure and heart rate to simulate pulsatility
• Adding simulated blood to the water tank and SVC vessel set increases realism
• Under-skin tunneling is supported on the platform
• Pre-set grooves allow extension modules for PICC practice
• Modular design reduces recurring training costs by replacing only consumables
• Realistic anatomy provides immersive hands-on experience for trainees
• Portable case included for transport

Models

• CVC-B01
• Hand Pump Version
• Applicable for ultrasound-guided CVC insertion and port access training
• Includes portable case, upper body base and all CVC spare parts (CVC-S01 to CVC-S08)

Spare Parts (included / available)

• Neck vessel set (SVC) (CVC-S01)
• Neck muscle pad (CVC-S02)
• Pre-tunneled neck muscle pad (CVC-S02A)
• Neck muscle base (CVC-S03)
• Water tank (CVC-S04)
• Hand pump (manual pulsation backup) (CVC-S05)
• 75 cm carotid artery for hand pump (CVC-S06)
• Extension tubing (CVC-S07)
• Connection tubing (CVC-S08)

Technical Specifications

• Net Dimensions (L×W×H): 37.5 cm × 29 cm × 18 cm
• Net Weight: 3.5 kg
• Gross Dimensions (L×W×H): 54 cm × 37.5 cm × 27 cm
• Gross Weight: 9.5 kg
• Self-healing neck muscle pad: up to 50 punctures
• Hand pump provides adjustable aortic pressure and heart rate for pulsatility simulation
