Temporary cardiac stimulator PG-B01

Overview
Electro-hydraulic pulse generator designed for medical simulation to reproduce pulsatile circulation for training in vascular access and ultrasound-guided procedures. It connects to compatible trainers, provides adjustable heart rate and blood pressure settings, and can operate independently or integrated into simulation platforms. Portable design allows transport in a dedicated case.

Procedures

• Typically used with the Central Venous Catheterization and Port Access Training Platform (CVC-B02) and the Femoral Vascular Access Trainer (FVA-B01 & FVA-B02)

Features

• Palpable vascular pulse
• Pulse visible under ultrasound guidance
• Operable standalone or with other products to generate pulsatile flow
• Container and artery installable and removable via quick connectors
• Adjustable heart rate and blood pressure
• Transportable in a portable case

Models

• PG-B01
• Designed to generate arterial pulsation
• Includes: portable case, unit, 150 cm valved artery with quick connectors at both ends (PG-S01), open-loop vessel & control valve set (PG-S02), extension liquid reservoir (PG-S03)
• Commonly paired with CVC-B02 and FVA-B01 & FVA-B02

Spare Parts

• 150 cm valved artery with quick connectors at both ends (PG-S01)
• Open-loop vessel & control valve set (PG-S02)
• Extension liquid reservoir (PG-S03)

Specification

• Heart Rate Range: 30–180 bpm
• Reservoir Capacity: 350–850 mL
• Net Dimensions (L×W×H): 25.5 cm × 18 cm × 11.3 cm
• Net Weight: 3 kg
• Gross Dimensions (L×W×H): 57 cm × 33.5 cm × 19.5 cm
• Gross Weight: 6.5 kg
• Includes: portable case, unit, 150 cm valved artery (PG-S01), open-loop vessel & control valve set (PG-S02), extension liquid reservoir (PG-S03)
