Electrocardiography software CTS Database

for cardiologycardiacfor ECG

Overview
CTS Database provides 19 standardized digital waveforms (16 CAL calibration files and 3 ANE analytical files) for diagnostic ECG manufacturers and software developers to perform digital verification of amplitude, interval and duration measurements in accordance with IEC 60601-2-25:2011. Files are intended for direct input into the device under test (DUT) to obtain test values and compare them with reference values.

Highlights
The CTS Database supports regulatory compliance testing for diagnostic ECGs by supplying defined digital signals and reference values required to assess whether device algorithms meet IEC 60601-2-25:2011 measurement criteria.

Digital tests
Load CAL and ANE files directly into the ECG DUT to record test outputs. Compare DUT results with provided reference values to evaluate amplitude, interval and duration measurement accuracy.

Signals (Types and Names)

• Calibration signal - CAL05000
• Calibration signal - CAL10000
• Calibration signal - CAL15000
• Calibration signal - CAL20000
• Calibration signal - CAL20002
• Calibration signal - CAL20100
• Calibration signal - CAL20110
• Calibration signal - CAL20160
• Calibration signal - CAL20200
• Calibration signal - CAL20210
• Calibration signal - CAL20260
• Calibration signal - CAL20500
• Calibration signal - CAL20502
• Calibration signal - CAL30000
• Calibration signal - CAL40000
• Calibration signal - CAL50000
• Analytical signal - ANE20000
• Analytical signal - ANE20001
• Analytical signal - ANE20002

Ordering information
Part No.: HE0-CD00001; Model: CTS Database. Package includes CAL and ANE digital files.

Compatibility and notes
Use with CTS/CSE Database Compliance Analyzer (CDCA) software to compare DUT-calculated test values with reference values. For analog system verification, convert digital CTS signals to analog using MECG 2.0 ECG Database Player for playback on ECG test setups.

Specifications

• Standard: Designed for verification to IEC 60601-2-25:2011 for diagnostic ECG testing.
• Waveforms: 19 digital waveforms (16 CAL files, 3 ANE files).
• File types: CAL (calibration) and ANE (analytical) files provided.
• Intended use: Direct digital input into ECG DUT to obtain amplitude, interval and duration test values.
• Software compatibility: CTS/CSE Database Compliance Analyzer (CDCA) for reference comparison.
• Analog testing: MECG 2.0 ECG Database Player can convert digital signals to analog for system-level verification.
• Ordering: Part No. HE0-CD00001; Model CTS Database.
