Radius compression plate A1219

distallockingstainless steel

Short description
Alignment: Left, Right | Head holes: 5 | Shaft holes: 3 or 5 | Materials & refs: SS316L (A1219, A1220), Titanium (A2219, A2220), SS316LVM (*A3219, *A3220).

Holes / Material / Length table

• 3 holes — SS316L: A1241003; Titanium: A2241003; SS316LVM: *A3241003 — Length: 91 mm
• 4 holes — SS316L: A1241004; Titanium: A2241004; SS316LVM: *A3241004 — Length: 103 mm
• 5 holes — SS316L: A1241005; Titanium: A2241005; SS316LVM: A3241005 — Length: 115 mm

Categories

• Trauma
• Radius

Features / Technical specifications

• Product type: Locking distal radius plate
• Intended alignment: Left and Right
• Head holes: 5
• Shaft holes: available in 3 or 5 configurations
• Available materials and references: SS316L (A1219, A1220), Titanium (A2219, A2220), SS316LVM (*A3219, *A3220)
• Hole-specific product codes and lengths: see table above (3 holes: 91 mm; 4 holes: 103 mm; 5 holes: 115 mm)
• Screw column options: shaft holes 3 or 5
