Telemedicine camera module e-CAM87_CUMI585_MOD

digital4K8 Mpx

Larger pixel size - 2.9μm High Signal-to-Noise ratio (SNR) Supported interfaces - GMSL / MIPI 4K images in both visible and IR lighting conditions e-CAM87_CUMI585_MOD is an 8 MP camera module based on 1/1.2" Sony Starvis 2 IMX585 image sensor. Sony STARVIS 2 is the latest technology with a wider dynamic range, it is the breakthrough for the Night Vision applications. This technology improves low-light performance and can capture high frame rate stunning images even at low lighting conditions. It has a CS-mount lens holder, allowing customers to choose and use the lens according to their requirements. Key features: Refer pdfDatasheet for complete frame rate details. Output format: YUV High-speed MIPI CSI-2 interface Frame sync CS-mount interchangeable lens holder for flexibility to choose a lens as per application requirements Small form-factor Sensor features: Sensor: IMX585 from Sony® Starvis 2 Focus Type: Fixed focus Chroma: Color Shutter type: Electronic Rolling Shutter Optical Format: 1/1.2" Output Format: YUV Pixel size: 2.9μm x 2.9μm Sensor Active Area: 3856 (H) x 2180 (V) Array Size: 3856 (H) x 2180 (V) Lens Holder: CS-Mount FOV: TBD Electrical & Mechanical: Operating Voltage: 3.3 V +/- 5% Operating Temperature Range: -30°C to 70°C Power requirements: TBD Size in mm (l x b): 30 x 30 mm Miscellaneous: Compliance: RoHS
