Medical sterilizer LDA-04

for researchveterinaryfor dental offices

Product Overview
Labotemp Dental Autoclave LDA-04 is a Class B steam sterilizer with a 23L stainless steel chamber, designed for vacuum-assisted sterilization of dental instruments, handpieces, implant kits and wrapped loads. The integrated steam generator and triple pre-vacuum cycle provide effective steam penetration up to 134°C for validated sterilization in clinics, hospitals, laboratories and veterinary practices.

Key Benefits

• Increased throughput: 23L chamber enables sterilization of multiple instrument sets per cycle to streamline instrument turnaround.
• Traceability and documentation: USB/U‑disk and printer support for cycle records and compliance tracking.
• Safety and reliability: built-in protections and interlock systems to ensure secure operation.

Features

• European Class B performance with triple pre‑vacuum (vacuum‑assisted sterilization)
• Sterilization temperature up to 134°C with integrated steam generator
• Microcomputer control with LCD touch buttons and automatic cycles
• Built‑in Bowie‑Dick (BD), Helix and vacuum test functions
• Automatic water filling, cold air discharge and steam exhaust systems
• Standard test interface and multiple safety protections (over‑temperature, over‑pressure, low water level)
• USB / U‑disk and printer connectivity for cycle documentation
• Buzzer reminders and automatic stop after cycle completion

Applications

• Sterilization of wrapped instruments, hollow devices, dental handpieces, implant and surgical kits.
• Suitable for laboratory glassware and reusable medical devices in dental clinics, hospitals, research labs and veterinary centers.
• Designed for workflows requiring vacuum‑assisted steam penetration, cycle traceability and infection control compliance.

Technical specifications

• Capacity: 23L (stainless steel chamber)
• Rated working temperature: 134°C
• Voltage: 110V/220V, 60Hz/50Hz
• Power: 2 kW
• Design pressure: 0.25 MPa
• Design temperature: 139°C
• Rated working pressure: 0.22 MPa
• Chamber dimensions (Ø × L): Ø250 × 452 mm
• Outer dimensions: 480 × 690 × 450 mm
• Packing size (L × W × H): 720 × 560 × 610 mm
• Net weight: 53 kg
• Gross weight: 60 kg
• Vacuum system: triple pre‑vacuum for effective air removal
• Control: intelligent microcomputer control with LCD touch interface
• Documentation: USB / U‑disk and printer support for cycle records
