Hospital LED panel DALSP-T

laboratorywall-mountedpendant

Overview
The DALSP-T 6P6 is a slim (12 mm) LED panel designed for offices and general areas. It provides uniform light diffusion for improved visual comfort and is a direct replacement for fluorescent fixtures in T25 modular ceilings.

Key features

• Dimensions compatible with standard modular ceilings (595 × 595 mm)
• Slim 12 mm profile suitable for shallow plenum
• Uniform opal diffusion for low glare (UGR < 19)
• Direct replacement for fluorescent technology
• Lifetime (L80B10): 50 000 hours

LED LIGHTING SOLUTION FOR OFFICES AND GENERAL LIGHTING
Innovation
Equipped with the latest LED technology, the DALSP-T 6P6 delivers stable luminous flux with a compact 12 mm depth. It can be installed recessed in a T25 grid, suspended with wires, or mounted on surfaces to fit different room configurations.

Savings
Low power consumption and a 50 000-hour lifetime (L80) reduce maintenance and operating costs compared with traditional fluorescent fixtures.

Versatility
With a compact design and neutral appearance, the DALSP-T 6P6 is suitable for offices, circulation areas and general lighting where visual comfort and space constraints are important.

Material
IP54 rated luminaire with white aluminium frame and opal diffuser.

Mounting
Typically installed on T25 grid modular ceilings; also available for surface mounting or suspension with metallic wires. Adaptable to room layout and customer requirements.

Power supply
The panel is powered by an external driver for connection to 230 VAC, 50 Hz mains.

Technical specifications

• Dimensions L × W × H: 595 × 595 × 12 mm
• Weight: 2 kg
• Lifetime (L80B10): 50 000 hours
• Colour temperatures: Cool White 6000 K (BF), Neutral White 4000 K (BN)
• Diffuser: Opal
• Luminous flux: 4000 Lumens
• Power: 40 Watts
• Operating temperature: -35 °C to +60 °C
• UGR: < 19
• Electrical insulation: Class II
• Photobiological risk: Group 0
• Warranty: 5 years
